Trek Wahoo 26 2023
2023 Youth
Estimate price |
559$
Weight | 10.21 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Groupset Altus -
Suspension Rigid -
Drivetrain 1 × 8 -
Brakes Rim
Sizing
Recommended size guide.
26"
146cm - 160cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alpha Silver Aluminum, 26''
Suspension Fork
Wahoo 26'' alloy with ThruSkew
Drivetrain
Rear Derailleur
Shimano Altus M310
Shift Levers
Shimano Altus M315, 8 speed
Cassette
Shimano HG31, 11-34, 8 speed
Crank
Alloy, 28T steel chain ring w/guard, 152mm length
Bottom Bracket
VP BC73, 73mm, threaded cartridge
Chain
KMC Z8.3, 8 speed
Pedals
Kids' 9/16''
Wheels
Front Hub
Formula alloy, 100mm ThruSkew
Rear Hub
Formula FM32 alloy, 135x5mm
Rims
Alloy 26'', 28h
Tires
26x1.95''
Brakes
Brakes
Alloy linear-pull
Brake Levers
Kids' alloy brake lever, black
Cockpit
Stem
Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 60mm length
Handlebar
Bontrager alloy, 31.8mm, 15mm rise, 580mm width
Grips
Kids' Kraton
Headset
1-1/8'' threadless
Seat
Saddle
Kid's 24'' size, padded
Seatpost
Bontrager Comp, 6061 alloy, 27.2mm, 8mm offset, 250mm length
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 26" |
|---|---|
| Stack Reach Ratio | 1.32 mm |
| Bottom Bracket Height | 279 mm |
| Front Center | 591 mm |
| Rake | 44 mm |
| Trail | 70 mm |
| Stack | 504 mm |
| Reach | 382 mm |
| Top Tube Length | 520 mm |
| Seat Tube Angle | 74.5 ° |
| Seat Tube Length | 320 mm |
| Head Tube Angle | 70 ° |
| Head Tube Length | 100 mm |
| Chainstay Length | 435 mm |
| Wheelbase | 1022 mm |
| Bottom Bracket Drop | 45 mm |
| Standover Height | 655 mm |
| Wheels | 26" |
| Rider Min Height | 146 cm |
| Rider Max Height | 160 cm |
About this model
Wahoo 26 belongs to the Trek Wahoo model. Trek released 37 bikes variations of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Trek Wahoo 20 2023 is the most economical model, with a starting price of 477$. Trek Wahoo 26 2023 on the other hand costs 559$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Youth bikes
If you want an acceptable Youth bike you should know that the average price is 278$. However, even if your budget is less than the average, you might still be able to get a top-quality Youth bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2023 for 559$. Comparing the average cost of a Youth bike to this one, you will see that Wahoo 26 price is 101.08% higher.
Youth bikes average weight
On a deeper look, we notice that the average weight of a Youth bike is 10.9 kg (24.03 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
Wahoo 26 weighs 10.21 kg (22.51 lbs) and is a bit lighter than the average. In short, the average Youth bike weight is 6.76% higher than this one.
Overview of components
Fork material
When it comes to the fork, this bike has an aluminum one, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels size
As for the wheels, Trek Wahoo 26 2023, has a 26″ aluminum model. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
When you want to stop the bike in time, the brakes are vital. The Wahoo 26 has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
Trek Wahoo 26 2023 is available in one size only. In conclusion, make sure it fits you, or look for another model.
