Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Wheels 700c -
Suspension Rigid
Sizing
Recommended size guide.
SM
160cm - 167cm
MD
170cm - 184cm
LG
181cm - 194cm
XL
192cm - 203cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Allround-Allroad 700c/650b disc, AE81 SuperMag, VAAST Allroad geometry, internal cable routing, dropper post ready. Rack and fender ready
Suspension Fork
VAAST Allround-Allroad full-carbon disc, rack & fender ready
Drivetrain
Bottom Bracket
T47, 85.5mm threaded (not included)
Cockpit
Headset
Integrated FSA No. 42/ACB, 1 1/8 x 1.5"
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.48 mm | 1.51 mm | 1.51 mm |
| Bottom Bracket Height | 281 mm | 281 mm | 281 mm | 281 mm |
| Front Center | 592 mm | 607 mm | 623 mm | 645 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 74 mm | 67 mm | 61 mm | 61 mm |
| Stack | 537 mm | 564 mm | 596 mm | 621 mm |
| Reach | 366 mm | 381 mm | 396 mm | 411 mm |
| Top Tube Length | 535 mm | 558 mm | 584 mm | 606 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 520 mm | 540 mm | 560 mm | 580 mm |
| Head Tube Angle | 70 ° | 71 ° | 72 ° | 72 ° |
| Head Tube Length | 115 mm | 140 mm | 170 mm | 195 mm |
| Chainstay Length | 426 mm | 426 mm | 426 mm | 426 mm |
| Wheelbase | 1009 mm | 1024 mm | 1039 mm | 1062 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 68 mm |
| Standover Height | 775 mm | 798 mm | 822 mm | 842 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 160 cm | 170 cm | 181 cm | 192 cm |
| Rider Max Height | 167 cm | 184 cm | 194 cm | 203 cm |
Model Overview
A/1 Frameset is a Vaast A1 model. 20 frames variations carry this model name so far. You can easily view all of the Vaast A1 frames models from 2020, here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Gravel frames
If you want to purchase a solid Gravel frame, it is important to know that the average cost is 1505$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel frame. To make sure you don’t pay a higher amount than normal for your frame, always do some components analysis and read reviews.
This frame was released in 2020 and its price was 1299$. If we compare this with the average Gravel frame cost we notice that the price is 15.86% lower.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 160 cm – 203 cm (5.25 ft – 6.66 ft). In conclusion, finding one for you shouldn’t be a problem.
