Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Magnesium -
Wheels 20" -
Travel Front 63mm -
Fork Suntour XCT
-
Groupset Altus -
Suspension Hardtail -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Youth MTB 20" AE81 ALLITE Super Mag - w/ replaceable hanger
Suspension Fork
SunTour 20" XCT JR, 63mm travel
Drivetrain
Rear Derailleur
Shimano Altus - 9-speed
Shift Levers
Shimano Altus - RapidFire Plus - 9-speed
Cassette
SunRace - 11/36T - 9-speed
Crank
Forged Alloy - 32T
Bottom Bracket
VP Components - sealed cartridge bearing
Chain
KMC X9
Wheels
Rims
Alex DA16 20" double wall aluminum - 24H
Spokes
14g stainless
Tires
Kenda Small Block Eight - 20" x 1.95"
Brakes
Brakes
Promax Hydraulic disc brakes w/Youth designed lever
Cockpit
Stem
VAAST 3D forged
Handlebar
VAAST MTB Youth - 6061 aluminum - 560mm width
Seat
Saddle
VAAST Youth Sport
Seatpost
VAAST Micro adjust aluminum - 27.2mm x 300mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 20" | 24" |
|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.46 mm |
| Front Center | 546 mm | 598 mm |
| Rake | 55 mm | 40 mm |
| Stack | 458 mm | 523 mm |
| Reach | 311 mm | 358 mm |
| Top Tube Length | 460 mm | 528 mm |
| Seat Tube Angle | 72 ° | 72 ° |
| Seat Tube Length | 265 mm | 310 mm |
| Head Tube Angle | 68 ° | 68 ° |
| Head Tube Length | 140 mm | 150 mm |
| Chainstay Length | 351 mm | 411 mm |
| Wheelbase | 896 mm | 1006 mm |
| Bottom Bracket Drop | 20 mm | 35 mm |
| Standover Height | 568 mm | 617 mm |
| Wheels | 20" | 20" |
About this model
Y/1 20″ completes the Vaast Y1 model. There are 7 bikes that carry this model name. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Vaast Y/1 20″ 2023 is the most economical model, with a starting price of 519$. Vaast Y/1 24″ 2023 on the other hand costs 649$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Youth bikes average price
Our math shows that the average cost of a dependable Youth bike is 278$. However, even though the average price of a Youth bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Vaast released this model in 2023, its price was 519$. Comparing this to the average Youth bike price, we see that the price is 86.69% more expensive.
Y/1 20″ components
Fork
This bike has the Suntour XCT fork installed. The fork’s travel is 63mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
As for the wheels, Vaast Y/1 20″ 2023, has a 20″ aluminum model. This wheel size is used on bike models like BMX, children, or folding bikes. In conclusion, you can use them better on-road, and less on technical terrain.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
