Bike details
Overview
Key information split into simple groups.
Frame summary
-
Category -
Frame Aluminum -
Wheels 700c -
Suspension Rigid -
Drivetrain Single Speed
Parts list
Components
Main components, grouped by system.
Bike components
Drivetrain
Cassette
11t X 32t
Crank
40t
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.42 mm | 1.46 mm | 1.48 mm | 1.48 mm | 1.49 mm |
| Bottom Bracket Height | 279 mm | 279 mm | 279 mm | 279 mm | 279 mm | 279 mm |
| Front Center | 588 mm | 590 mm | 597 mm | 607 mm | 612 mm | 637 mm |
| Rake | 47 mm | 47 mm | 47 mm | 47 mm | 47 mm | 47 mm |
| Trail | 77 mm | 67 mm | 64 mm | 62 mm | 73 mm | 58 mm |
| Stack | 523 mm | 547 mm | 568 mm | 589 mm | 610 mm | 629 mm |
| Reach | 376 mm | 385 mm | 389 mm | 398 mm | 412 mm | 421 mm |
| Seat Tube Angle | 75 ° | 75 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 490 mm | 515 mm | 535 mm | 560 mm | 580 mm | 590 mm |
| Head Tube Angle | 70 ° | 71.5 ° | 72 ° | 72.5 ° | 73 ° | 73 ° |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1014 mm | 1017 mm | 1023 mm | 1033 mm | 1034 mm | 1064 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
A.D.D. Frameset completes the Vandessel Add model. Van Dessel released 3 frames variations of this model so far. Check out the entire range from 2019 of this model, by clicking this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Cyclocross frames average price
Our math shows that the average cost of a dependable Cyclocross frame is 1405$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Cyclocross frame. To sum up, when you purchase your frame, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2019 for 999$. In conclusion, this frame price is 40.64% smaller than the price of the average Cyclocross frame.
Overview of components
Fork material
When it comes to the fork, this frame has a carbon one, so, it won’t add up to much weight to your frame. However, the price you have to pay for a carbon fork is considerably higher.
