Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 120mm -
Fork RockShox SID Select
-
Groupset GX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 177cm
LG
175cm - 185cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
VIATHON M.1 MOUNTAIN 29" CARBON FRAME
Suspension Fork
ROCKSHOX SID SELECT RL, 120MM TRAVEL, 51MM OFFSET
Drivetrain
Rear Derailleur
SRAM GX EAGLE
Shift Levers
SRAM GX EAGLE TRIGGER SHIFTER
Cassette
SRAM XG-1275 EAGLE 10-50T
Crank
SRAM GX EAGLE DUB 32T
Bottom Bracket
SRAM DUB BSA 73MM
Chain
SRAM GX EAGLE 12-SPEED
Wheels
Rims
STAN'S NO TUBES ARCH S1 TEAM 29 6-BOLT DISC
Tires
CONTINENTAL X-KING 29 X 2.3 FRONT / 2.2 REAR FOLDING BLACK CHILI
Brakes
Brakes
SRAM LEVEL TL
Disk Rotors
SRAM CENTERLINE 6-BOLT 160MM
Cockpit
Stem
FSA AFTERBURNER 70 MM
Handlebar
FSA AFTERBURNER 740MM
Grips
ERGON GA20
Headset
FSA
Seat
Saddle
FIZIK TUNDRA M5 126MM S-Alloy
Seatpost
FSA AFTERBURNER 400MM 0 OFFSET
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.58 mm | 1.48 mm | 1.43 mm |
| Bottom Bracket Height | 318 mm | 318 mm | 318 mm |
| Front Center | 659 mm | 685 mm | 711 mm |
| Rake | 51 mm | 51 mm | 51 mm |
| Trail | 86.1 mm | 86.1 mm | 86.1 mm |
| Stack | 627 mm | 627 mm | 636 mm |
| Reach | 397 mm | 423 mm | 445.5 mm |
| Top Tube Length | 580 mm | 606 mm | 631 mm |
| Seat Tube Angle | 73.6 ° | 73.6 ° | 73.6 ° |
| Seat Tube Length | 406 mm | 432 mm | 476 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 90 mm | 90 mm | 100 mm |
| Chainstay Length | 446 mm | 446 mm | 446 mm |
| Wheelbase | 1099 mm | 1125 mm | 1151 mm |
| Bottom Bracket Drop | 56 mm | 56 mm | 56 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 175 cm |
| Rider Max Height | 170 cm | 177 cm | 185 cm |
About this model
M.1 GX Eagle completes the Viathon M1 model. There are 10 bikes that carry this model name. You can get a glimpse at all models from 2021, by clicking on this link.
Model range prices
The most economical model, the Viathon M.1 GX Eagle 2021 has a starting price of 2198$. Viathon M.1 XX1 Eagle AXS 2021 on the other hand is the most expensive at 6498$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail bikes average price
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2021 and its price was 2198$. Comparing this to the average Trail bike price, we see that the price is 25.66% lower.
M.1 GX Eagle components
Fork
Viathon M.1 GX Eagle 2021 bike is equipped with the RockShox SID Select fork, and has 120mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
The M.1 GX Eagle 2021 bike is equipped with 29″ aluminum wheels when leaving the factory. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
Nothing is more important on a bike than its ability to brake properly. Viathon M.1 GX Eagle is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
This bike is available in 3 sizes. They vary from 158 cm – 185 cm (5.18 ft – 6.07 ft). In conclusion, finding one for you shouldn’t be a problem.
