Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset RED eTAP -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
52cm
158cm - 170cm
54cm
168cm - 177cm
56cm
175cm - 185cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
VIATHON R.1 ROAD FRAME FULL CARBON
Suspension Fork
VIATHON R.1 ROAD FORK FULL CARBON
Drivetrain
Rear Derailleur
SRAM RED ETAP AXS
Front Derailleur
SRAM RED ETAP AXS
Shift Levers
SRAM RED ETAP AXS HRD SHIFT-BRAKE SYSTEM
Cassette
SRAM RED XG-1290 10-28
Crank
SRAM RED D1 DUB 48-35T
Bottom Bracket
SRAM DUB PF30
Chain
SRAM RED D1
Wheels
Rims
HED VANQUISH 4 GP CARBON CLINCHER, CENTER LOCK HUBS
Tires
CONTINENTAL GRAND PRIX 5000 S 25mm BLACK CHILI
Brakes
Brake Levers
SRAM RED ETAP AXS HRD SHIFT-BRAKE SYSTEM
Disk Rotors
SRAM CLX CENTERLOCK R, 160MM
Cockpit
Stem
ZIPP SL SPEED 110MM
Handlebar
ZIPP SL-70 CARBON
Headset
FSA
Seat
Saddle
FIZIK ANTARES R1 141mm CARBON RAIL
Seatpost
ZIPP SL SPEED 27.2MM
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 52cm | 54cm | 56cm | 57.5cm | 59cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.42 mm | 1.45 mm | 1.47 mm | 1.5 mm |
| Bottom Bracket Height | 264 mm | 264 mm | 264 mm | 264 mm | 269 mm |
| Front Center | 578 mm | 583 mm | 590 mm | 596 mm | 613 mm |
| Rake | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 67.4 mm | 67.4 mm | 67.4 mm | 67.4 mm | 67.4 mm |
| Stack | 528 mm | 551 mm | 570 mm | 585 mm | 613 mm |
| Reach | 381 mm | 387 mm | 392 mm | 398 mm | 409 mm |
| Top Tube Length | 535 mm | 551 mm | 566 mm | 577 mm | 603 mm |
| Seat Tube Angle | 73.7 ° | 73.4 ° | 73 ° | 73 ° | 72.4 ° |
| Seat Tube Length | 520 mm | 540 mm | 560 mm | 575 mm | 590 mm |
| Head Tube Angle | 72 ° | 72.8 ° | 73.2 ° | 73.7 ° | 74 ° |
| Head Tube Length | 124 mm | 146 mm | 164 mm | 178 mm | 211 mm |
| Chainstay Length | 407 mm | 407 mm | 409 mm | 409 mm | 409 mm |
| Wheelbase | 974 mm | 980 mm | 989 mm | 994 mm | 1013 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm | 67 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 175 cm | cm | cm |
| Rider Max Height | 170 cm | 177 cm | 185 cm | cm | cm |
About this model
R.1 Red eTap AXS belongs to the Viathon R1 model. Viathon released 12 bikes variations of this model so far. Check out the entire range from 2021 of this model, by clicking this link.
Model range prices
The most economical model, the Viathon R.1 105 2021 has a starting price of 2198$. Viathon R.1 Red eTap AXS 2021 on the other hand is the most expensive at 6998$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Race bikes average price
According to our calculations, the average cost of a Race bike that is reliable is 3350$. However, even if your budget is less than the average, you might still be able to get a top-quality Race bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2021 for 6998$. Comparing the average cost of a Race bike to this one, you will see that R.1 Red eTap AXS price is 108.9% higher.
R.1 Red eTap AXS components
Fork material
R.1 Red eTap AXS has a carbon fork, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
The wheels on R.1 Red eTap AXS are the 700c carbon type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Viathon R.1 Red eTap AXS has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
