Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
52cm
158cm - 170cm
54cm
168cm - 177cm
56cm
175cm - 185cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
VIATHON R.1 ROAD FRAME FULL CARBON
Suspension Fork
VIATHON R.1 ROAD FORK FULL CARBON
Drivetrain
Rear Derailleur
SHIMANO ULTEGRA RD-R8000
Front Derailleur
SHIMANO ULTEGRA FD-R8000
Shift Levers
SHIMANO ULTEGRA ST-R8020
Cassette
SHIMANO ULTEGRA CS-R8000 11-28
Crank
SHIMANO ULTEGRA FC-R8000 50-34T
Bottom Bracket
ROTOR PRESS FIT 4624
Chain
SHIMANO CN-HG701-11
Wheels
Rims
KNIGHT 35mm TLA CARBON CLINCHER KNIGHT CENTER LOCK HUBS
Tires
CONTINENTAL GRAND PRIX 5000 S 25mm BLACK CHILI
Brakes
Brake Levers
SHIMANO ULTEGRA ST-R8020
Disk Rotors
SHIMANO SM-RT800, 160MM
Cockpit
Stem
ZIPP SERVICE COURSE SL 110MM
Handlebar
FIZIK SERVICE COURSE SL-70
Headset
FSA
Seat
Saddle
FIZIK ANTARES R3 141mm K:ium rail
Seatpost
ZIPP SERVICE COURSE SL 0 OFFSET
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 52cm | 54cm | 56cm | 57.5cm | 59cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.42 mm | 1.45 mm | 1.47 mm | 1.5 mm |
| Bottom Bracket Height | 264 mm | 264 mm | 264 mm | 264 mm | 269 mm |
| Front Center | 578 mm | 583 mm | 590 mm | 596 mm | 613 mm |
| Rake | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 67.4 mm | 67.4 mm | 67.4 mm | 67.4 mm | 67.4 mm |
| Stack | 528 mm | 551 mm | 570 mm | 585 mm | 613 mm |
| Reach | 381 mm | 387 mm | 392 mm | 398 mm | 409 mm |
| Top Tube Length | 535 mm | 551 mm | 566 mm | 577 mm | 603 mm |
| Seat Tube Angle | 73.7 ° | 73.4 ° | 73 ° | 73 ° | 72.4 ° |
| Seat Tube Length | 520 mm | 540 mm | 560 mm | 575 mm | 590 mm |
| Head Tube Angle | 72 ° | 72.8 ° | 73.2 ° | 73.7 ° | 74 ° |
| Head Tube Length | 124 mm | 146 mm | 164 mm | 178 mm | 211 mm |
| Chainstay Length | 407 mm | 407 mm | 409 mm | 409 mm | 409 mm |
| Wheelbase | 974 mm | 980 mm | 989 mm | 994 mm | 1013 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm | 67 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 175 cm | cm | cm |
| Rider Max Height | 170 cm | 177 cm | 185 cm | cm | cm |
About this model
R.1 Ultegra Outlet is a Viathon R1 model. Viathon released 12 bikes variations of this model so far. Check out the entire range from 2020 of this model, by clicking this link.
Model range prices
Viathon R.1 105 2020 is the cheapest bike model and costs 2198$. Viathon R.1 Red eTap AXS 2020 is the most expensive one and costs 6998$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Race bikes average price
If you want to purchase a solid Race bike, it is important to know that the average cost is 3350$. However, even though the average price of a Race bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
At the moment of the release date, Viathon R.1 Ultegra Outlet price was 3575$. In conclusion, this bike price is 6.72% higher than the price of the average Race bike.
R.1 Ultegra Outlet components
Fork material
When it comes to the fork, this bike has a carbon one, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
When it comes to wheels, the R.1 Ultegra Outlet bike is equipped with the 700c carbon model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The R.1 Ultegra Outlet comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
