Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 140mm -
Travel Rear 120mm -
Fork RockShox Sektor
-
Groupset SLX, Deore -
Suspension Full -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Hydroformed 6061-T6 Aluminium Frame, with Four-bar V-Link Rear Suspension, 120mm Travel
Suspension Fork
RockShox Sektor Silver TK, 29 Solo Air, Tapered Alloy Steerer, 15mm Maxle Lite, 140mm Travel
Rear Shock
RockShox Monarch RT, 190mm x 51mm
Drivetrain
Rear Derailleur
Shimano SLX RD-M675, Shadow Plus
Front Derailleur
Shimano Deore FD-M616
Shift Levers
Shimano SLX SL-M670, Rapid Fire Plus
Cassette
Shimano, 11t-36t, 10-Speed
Crank
FSA Comet MegaExo, 170mm, 38t x 24t
Bottom Bracket
FSA MegaExo (BSA)
Chain
KMC X10, 10-Speed
Wheels
Front Hub
Easton XR - 6 Bolt, 100mm x 15mm
Rear Hub
Easton XR - 6 Bolt, 142mm x 12mm
Rims
Easton EA70 XL Disc 29”
Tires
Continental X-King, 29” x 2.4” Front/29” x 2.2” Rear
Brakes
Brakes
Shimano SLX BR-M675 Hydraulic Disc, 180mm Rotors
Cockpit
Stem
Vitus, 3D Forged 6061-T6 Aluminium, +/- 7 Degree Rise, 60mm Extension
Handlebar
Vitus Flat Bar, 6061 Double Butted Alloy, 740mm Wide
Headset
FSA Orbit 1.5 Zero Stack, (No.57), 1.1/8” - 1.5”
Seat
Saddle
Vitus
Seatpost
Vitus Alloy, 6061-T6, 15mm Offset, 31.6mm x 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Bottom Bracket Height | 346 mm | 346 mm | 346 mm |
| Reach | 385.18 mm | 407.67 mm | 424.67 mm |
| Top Tube Length | 569 mm | 597 mm | 614 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 394 mm | 445 mm | 495 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 454 mm | 454 mm | 454 mm |
| Bottom Bracket Drop | 28 mm | 28 mm | 28 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
Escarpe 290 2014 completes the Vitus Escarpe model. There are 77 bikes that carry this model name. You can easily view all of the Vitus Escarpe bikes models from 2014, here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Trail bikes average price
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Trail bikes average weight
Trail bikes have an average weight of 12.98 kg (28.62 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
considerably heavier than average, Escarpe 290 2014 has a weight of 14.4 kg (31.75 lbs). To sum up, it’s 10.94% heavier than the average weight of Trail bikes.
Overview of components
Fork
The Escarpe 290 2014 comes factory-installed with the RockShox Sektor fork. This has a travel range of 140mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Fork material
Escarpe 290 2014 has an aluminum fork, which is a lighter material. However, it is not as tough, nor durable as steel is.
Rear Shock
As for the rear shock, this bike has the RockShox Monarch RT model, with a travel of 120mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
The Escarpe 290 2014 2014 bike is equipped with 29″ aluminum wheels when leaving the factory. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Escarpe 290 2014 comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, it won’t be difficult to find the right one for you.
