Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 140mm -
Travel Rear 140mm -
Fork RockShox Sektor
-
Groupset X5, X7 -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061-T6 hydroformed aluminium, four-bar V-Link rear suspension, 140mm travel
Suspension Fork
RockShox Sektor TK Solo Air, 140mm travel, 15mm thru-axle / RockShox Monarch RT
Drivetrain
Rear Derailleur
SRAM X5
Front Derailleur
SRAM X7
Shift Levers
SRAM X5
Cassette
SRAM PG-1030, 11t-36t, 10-speed
Crank
SRAM S1000 GXP, 175mm, 39tx26t
Bottom Bracket
SRAM GXP (BSA)
Chain
SRAM PC-1031, 10-speed
Wheels
Front Hub
Formula Disc, 100mm x 15mm
Rear Hub
Formula Disc, 142mm x 12mm
Tires
Maxxis High Roller, 26”x2.35”, 60a MaxxPro
Brakes
Brakes
Avid Elixir 3 hydraulic disc, 180mm
Cockpit
Stem
Easton EA50, 60mm, 8 degree rise
Handlebar
Vitus alloy riser, 730mm wide, 25mm rise
Headset
FSA Orbit 1.5 Zero Stack, 1-1/8” to 1.5”
Seat
Saddle
Vitus
Seatpost
Vitus alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Bottom Bracket Height | 336 mm | 336 mm | 336 mm |
| Front Center | 672 mm | 697 mm | 723 mm |
| Top Tube Length | 571 mm | 596 mm | 621 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 406 mm | 457.2 mm | 508 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 120 mm | 120 mm | 130 mm |
| Chainstay Length | 441 mm | 441 mm | 441 mm |
| Wheelbase | 1112 mm | 1137 mm | 1163 mm |
| Bottom Bracket Drop | 6 mm | 6 mm | 6 mm |
| Wheels | 26" | 26" | 26" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
Escarpe II 2013 is a Vitus Escarpe model. Vitus released 77 bikes variations of this model so far. Take a sneak peek at all Vitus Escarpe bikes models from 2013, by clicking here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail bikes average price
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Average weight for Trail bikes
If we make a quick analysis of the average weight of a Trail bike, we get 12.98 kg (28.62 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
With a weight of 14.3 kg (31.53 lbs), Vitus bike is considerably heavier than average. In short, the average Trail bike weight is 10.17% lower than this one.
Escarpe II 2013 components
Fork
The Escarpe II 2013 comes factory-installed with the RockShox Sektor fork. This has a travel range of 140mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
When it comes to wheels, the Escarpe II 2013 bike is equipped with the 26″ model. Being a little smaller, these wheels will fit both small and tall riders. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
Escarpe II 2013 comes in 3 sizes, that range from 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, it won’t be difficult to find the right one for you.
