Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Apex 1 -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
157cm - 164cm
SM
161cm - 169cm
MD
166cm - 174cm
LG
171cm - 177cm
XL
174cm - 184cm
XXL
181cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Mach 3 Aluminium, 6061-T6 Double Butted Aluminium, Internal Cable Routing, QR, Flat Mount, Mud Guard Mounts, Rack Mounts
Suspension Fork
Mach 3 Carbon, UD Carbon, Tpered Steerer, 100 x 12mm Axle, Flat Mount, Mud Guard Mounts
Drivetrain
Rear Derailleur
SRAM APEX 1, 11 Speed, Long Cage
Front Derailleur
N/A, N/A
Shift Levers
SRAM APEX Trigger Shifter, 11 Speed
Cassette
Sunrace MS8, 11-36T
Crank
SRAM APEX X-Sync, 42T, XS:165mm S:170mm M:170mm L:170mm XL:175mm XXL: 175mm
Bottom Bracket
SRAM GXP, BSA Threaded, English
Chain
KMC X11 11 Speed
Wheels
Front Hub
Vitus KT TX5F-12, Centre Lock Disc Brake, 32 Hole
Rear Hub
Vitus KT, CRR6L4, Centre Lock Disc Brake, 32 Hole, QR, Shimano HG Freehub
Rims
WTB ST i23 TCS 2.0 700c, 32 Hole,
Spokes
N/A 16mm Nipple
Tires
Vee G-Sport, 700c x 38, MPC, B-Proof
Brakes
Brakes
Shimano UR300 Hydraulic Disc, BL-MT201-R/L & BR-UR300-F/R, Flat Mount
Disk Rotors
Shimano RT54, Front:160mm, Rear:160mm
Cockpit
Stem
Vitus Integrated Flat Bar / Stem 6061 Aluminium, XS:80mm S:90mm M:100mm L:100mm XL:110mm XXL: 110mm
Handlebar
Vitus Integrated Flat Bar / Stem 6061 Aluminium, 4 Degree Rise, 9 Degree Sweep, XS:380mm S:400mm M:420mm L:420mm XL:440mm XXL:440mm
Grips
Vitus Ergo Anti Slip, Ergonomic Shape, Integrated Lock Ring
Headset
ACROS Aix-Low R3 Sealed Bearings, OD46, 1 1/8” – 1 ½”, 41.8 / 28.6 – 52 / 40
Seat
Saddle
VITUS Steel Rail
Seatpost
VITUS Aluminium 27.2mm, 12mm Offset, 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.34 mm | 1.36 mm | 1.38 mm | 1.38 mm | 1.39 mm | 1.4 mm |
| Front Center | 607.8 mm | 611.6 mm | 617.4 mm | 627.5 mm | 638.69 mm | 650.4 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 79 mm | 77 mm | 73 mm | 70 mm | 68 mm | 66 mm |
| Stack | 531 mm | 541 mm | 557 mm | 572 mm | 588 mm | 606 mm |
| Reach | 395 mm | 399 mm | 405 mm | 414 mm | 423 mm | 432 mm |
| Top Tube Length | 550.5 mm | 560 mm | 573.5 mm | 587 mm | 603.16 mm | 619.45 mm |
| Seat Tube Angle | 73.5 ° | 73.25 ° | 73 ° | 73 ° | 72.8 ° | 72.65 ° |
| Seat Tube Length | 440 mm | 460 mm | 480 mm | 500 mm | 520 mm | 540 mm |
| Head Tube Angle | 70 ° | 70.4 ° | 71 ° | 71.4 ° | 71.7 ° | 72 ° |
| Head Tube Length | 112 mm | 122 mm | 136 mm | 150 mm | 166 mm | 184 mm |
| Chainstay Length | 444 mm | 444 mm | 444 mm | 444 mm | 444 mm | 444 mm |
| Wheelbase | 1043 mm | 1047 mm | 1053 mm | 1063 mm | 1074 mm | 1086 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 157 cm | 161 cm | 166 cm | 171 cm | 174 cm | 181 cm |
| Rider Max Height | 164 cm | 169 cm | 174 cm | 177 cm | 184 cm | 190 cm |
About this model
Mach 3 VRX is part of the Vitus Mach model. Vitus launched 37 bikes of this model so far. Check out the entire range from 2021 of this model, by clicking this link.
Model range prices
Vitus Mach 3 VR 2021 is the most affordable bike of this model and has a price of 704$. On the other hand, Vitus Mach 3 VRX 2021, is the most expensive and costs 1094$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Hybrid bikes
If you want an acceptable Hybrid bike you should know that the average price is 562$. However, even though the average price of a Hybrid bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
At the moment of the release date, Vitus Mach 3 VRX price was 1094$. If we compare this with the average Hybrid bike cost we notice that the price is 94.66% higher.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
When it comes to wheels, the Mach 3 VRX bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Vitus Mach 3 VRX is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
This bike is available in 6 sizes. They vary from 157 cm – 190 cm (5.15 ft – 6.23 ft). In short, it won’t be difficult to find the right one for you.
