Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Fork RockShox SID
-
Groupset X9, SRAM -
Suspension Hardtail -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
T700 High-modulus HM-UD carbon
Suspension Fork
RockShox SID RL 29 Solo Air, 100mm travel, 15mm thru-axle
Drivetrain
Rear Derailleur
SRAM X9
Front Derailleur
SRAM X9
Shift Levers
SRAM X9, Type 2
Cassette
SRAM PG-1050, 11t-36t, 10-speed
Crank
SRAM S1400 2.2 PF30, 175mm, 39t x 26t
Bottom Bracket
SRAM Press Fit 30 (PF30)
Chain
SRAM PC-1031, 10-Speed
Wheels
Front Hub
Easton XC Disc, 100mm x 15mm
Rear Hub
Easton XC Disc, 135mm x QR
Rims
Easton EA70 XC
Tires
Maxxis Aspen, 29”x2.1”, 62a /60a
Brakes
Brakes
Avid Elixir 7 Carbon hydraulic disc, 160mm rotors
Cockpit
Stem
Easton EA70, 8 degree rise
Handlebar
Easton EA70 XC flat bar, 685mm
Headset
FSA Orbit 1.5B Zero Stack, 1-1/8” to 1.5”
Seat
Saddle
Vitus
Seatpost
Easton EA70
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Bottom Bracket Height | 313 mm | 313 mm | 313 mm | 313 mm |
| Front Center | 639 mm | 656 mm | 676 mm | 696 mm |
| Top Tube Length | 580.7 mm | 597.3 mm | 616.3 mm | 635.4 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 394 mm | 438 mm | 483 mm | 533 mm |
| Head Tube Angle | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 105 mm | 110 mm | 125 mm | 145 mm |
| Chainstay Length | 433 mm | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1065 mm | 1082 mm | 1102 mm | 1122 mm |
| Bottom Bracket Drop | 61 mm | 61 mm | 61 mm | 61 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Rapide 29 2013 completes the Vitus Rapide model. Vitus released 45 bikes variations of this model so far. Take a sneak peek at all Vitus Rapide bikes models from 2013, by clicking here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Crosscountry bikes average price
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Crosscountry bikes average weight
The average weight for Crosscountry bikes is 12.4 kg (27.34 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
With a weight of 10.9 kg (24.03 lbs), Vitus bike is considerably lighter than average. In short, the average Crosscountry bike weight is 13.76% higher than this one.
Overview of components
Fork
The fork installed on this bike is the RockShox SID model. The travel on this model is 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
When leaving the production line, the Rapide 29 2013 model has 29″ aluminum wheels. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
Rapide 29 2013 comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
