Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Fork RockShox SID
-
Groupset X01 Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
149cm - 152cm
MD
167cm - 152cm
LG
177cm - 182cm
XL
188cm - 182cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Race Ready Carbon Frameset
Suspension Fork
100mm RockShox Sid RL Remote, 29 inch
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM X01 Eagle, 12 speed
Front Derailleur
N/A
Shift Levers
SRAM X01 Eagle, 1 x 12
Cassette
SRAM X01 Eagle XG-1295, 10-50T, 12 speed
Crank
SRAM XO1 Eagle, Dub 175mm, 32T
Bottom Bracket
SRAM, Dub
Chain
SRAM GX Eagle, 12 speed
Wheels
Front Hub
DT Swiss X 1900 Spline 25, 100x15mm
Rear Hub
DT Swiss X 1900 Spline 25, 142x12mm
Rims
DT Swiss X 1900 Spline 25, 29 inch
Spokes
N/A
Tires
Maxxis Ardent Race (F) Maxxis Ikon (R), 3C, 29x2.2”, 3C/EXO/TR/ MaxxSpeed (F) 3C, 29x2.2”, 3C/EXO/TR/ MaxxSpeed (R)
Brakes
Brakes
SRAM Level TL, 180mm rotor
Cockpit
Stem
FSA Afterburner, S:70MM M:80MM L:90MM XL:100MM
Handlebar
FSA Afterburner, 740mm 0 rise 31.8mm
Headset
FSA
Seat
Saddle
Nukeproof Neutron
Seatpost
Vitus, 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.57 mm | 1.57 mm | 1.52 mm | 1.48 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 662 mm | 672 mm | 693 mm | 713 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 102 mm | 103 mm | 103 mm | 105 mm |
| Stack | 612 mm | 622 mm | 631 mm | 640.5 mm |
| Reach | 390 mm | 397 mm | 414 mm | 431.5 mm |
| Top Tube Length | 585 mm | 595 mm | 615 mm | 635 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 395 mm | 445 mm | 483 mm | 533 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 105 mm | 115 mm | 125 mm | 135 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1090 mm | 1100 mm | 1121 mm | 1141 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 149 cm | 167 cm | 177 cm | 188 cm |
| Rider Max Height | 152 cm | 152 cm | 182 cm | 182 cm |
About this model
Rapide CRX belongs to the Vitus Rapide model. Vitus launched 45 bikes of this model so far. Take a sneak peek at all Vitus Rapide bikes models from 2019, by clicking here.
Model range prices
Vitus Rapide 2019 is the most economical model, with a starting price of 1094$. Vitus Rapide CRX 2019 on the other hand costs 3040$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Crosscountry bikes
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2019 for 3040$. Comparing the average cost of a Crosscountry bike to this one, you will see that Rapide CRX price is 59.58% higher.
Overview of components
Fork
This bike has the RockShox SID fork installed. The fork’s travel is 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
When it comes to wheels, the Rapide CRX bike is equipped with the 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
Vitus Rapide CRX bike has 4 sizes, in the range of 149 cm – 182 cm (4.89 ft – 5.97 ft). In short, it won’t be difficult to find the right one for you.
