Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Sora -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
158cm - 167cm
SM
165cm - 173cm
MD
169cm - 180cm
LG
177cm - 186cm
XL
183cm - 191cm
XXL
186cm - 194cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061-T6 Alloy Double Butted
Suspension Fork
UD Carbon with Alloy Steerer – Tapered
Drivetrain
Rear Derailleur
Shimano Sora R3000
Front Derailleur
Shimano Sora R3000
Shift Levers
Shimano Sora R3000
Cassette
Shimano CS-HG400 9Sp - 11-32T
Crank
Shimano Sora FC-R3000 50-34T
Bottom Bracket
BSA
Chain
KMC HG-53
Wheels
Front Hub
KT
Rear Hub
KT
Rims
Vitus
Tires
Vittoria Zaffiro 28c Wire Bead
Brakes
Brakes
Tektro MD-C510 Mechanical Flat Mount 160mm Rotors
Cockpit
Stem
Vitus
Handlebar
Vitus
Headset
FSA
Seat
Saddle
Vitus
Seatpost
Vitus
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.4 mm | 1.45 mm | 1.49 mm | 1.52 mm | 1.48 mm |
| Bottom Bracket Height | 266 mm | 266 mm | 266 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 582.7 mm | 585.9 mm | 591.2 mm | 596.1 mm | 608.3 mm | 631.1 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 64 mm | 48 mm | 50 mm | 51 mm | 50 mm | 50 mm |
| Stack | 509.2 mm | 535.2 mm | 554.4 mm | 573.5 mm | 592.6 mm | 605 mm |
| Reach | 371 mm | 382 mm | 383.5 mm | 384.5 mm | 389 mm | 408.2 mm |
| Top Tube Length | 508 mm | 533 mm | 543 mm | 553 mm | 568 mm | 588 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 73.5 ° | 73.25 ° | 73.5 ° |
| Seat Tube Length | 500 mm | 520 mm | 540 mm | 560 mm | 580 mm | 600 mm |
| Head Tube Angle | 71 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 117 mm | 137 mm | 157 mm | 177 mm | 197 mm | 210 mm |
| Chainstay Length | 410 mm | 408 mm | 408 mm | 408 mm | 408 mm | 408 mm |
| Wheelbase | 981 mm | 984 mm | 989 mm | 994 mm | 1007 mm | 1030 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 165 cm | 169 cm | 177 cm | 183 cm | 186 cm |
| Rider Max Height | 167 cm | 173 cm | 180 cm | 186 cm | 191 cm | 194 cm |
About this model
Razor Disc VR completes the Vitus Razor model. 58 bikes variations carry this model name so far. Check out the entire range from 2019 of this model, by clicking this link.
Model range prices
Vitus Razor 2019 is the cheapest bike model and costs 607$. Vitus Razor Disc VR 2019 is the most expensive one and costs 911$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Endurance bikes
Our math shows that the average cost of a dependable Endurance bike is 2346$. However, you could also get a good Endurance bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 911$. If we compare this with the average Endurance bike cost we notice that the price is 157.52% smaller.
Razor Disc VR components
Fork material
The fork on this bike is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
When it comes to wheels, the Razor Disc VR bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Vitus Razor Disc VR is equipped with Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
This bike is available in 6 sizes. They vary from 158 cm – 194 cm (5.18 ft – 6.36 ft). In conclusion, you won’t have a problem finding one that suits you.
