Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 700c -
Groupset Claris -
Suspension Rigid -
Drivetrain 2 × 8 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Razor Aluminium, 6061-T6 Double Butted Aluminium, Rim Brake, Internal Cable Routing, Mudguard Mounts, 130mm x 9mm QR Axle
Suspension Fork
Razor Carbon, UD Carbon, Tapered Aluminium Steerer, QR, Mudguard Mounts
Drivetrain
Rear Derailleur
Shimano Claris R2000, RD-R2000, 8 Speed
Front Derailleur
Shimano Claris R2000, FD-R2000, Braze-On, 2 x 8 Speed
Shift Levers
Shimano Claris R2000, ST-R2000-R, 8 Speed
Cassette
Sunrace M66, 8 Speed, 11-32T
Crank
Prowheel Ounce, 50/34T, 8 Speed, XXS:165mm XS:165mm S:165mm M:170mm L:175mm
Bottom Bracket
Cartridge Square Taper, BSA Threaded, 68mm, English
Chain
KMC HG-40, 8 Speed
Wheels
Front Hub
Vitus KT, 515F, 24 Hole, QR
Rear Hub
Vitus KT, GTER, 28 Hole, QR, HG Freehub
Rims
Vitus Shining, A-X240, 700c, 24 Hole, Eyelets
Tires
Kenda Kwick Roller Sport, 700c x 28c
Brakes
Brakes
Tektro R317, Dual Pivot, Long Reach
Disk Rotors
N/A, N/A
Cockpit
Stem
Vitus 6061 Aluminium, Bar Bore 31.8mm, +/- 7 degrees, XXS:70mm XS:70mm S:80mm M:90mm L:110mm
Handlebar
Vitus 6061 Aluminium, 72mm Reach, 120mm Drop, XXS:380mm XS:380mm S:380mm M:400mm L:420mm
Grips
Vitus, EVA Cork
Headset
ACROS Aix 322 R3, Sealed Bearings, OD46, 1 1/8” – 1 ½”, 41.8 / 28.6 – 52 / 40
Seat
Saddle
Vitus, Steel Rail
Seatpost
Vitus 6061 Aluminium, 27.2mm x 350mm, 12mm Offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.39 mm | 1.42 mm | 1.45 mm | 1.49 mm |
| Bottom Bracket Height | 269 mm | 269 mm | 269 mm | 269 mm | 269 mm |
| Front Center | 579 mm | 585 mm | 588 mm | 595 mm | 598 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 69 mm | 60 mm | 59 mm | 56 mm | 52 mm |
| Stack | 502 mm | 519 mm | 534 mm | 554 mm | 573 mm |
| Reach | 367 mm | 374 mm | 377 mm | 381 mm | 385 mm |
| Top Tube Length | 498 mm | 520 mm | 531 mm | 545 mm | 559 mm |
| Seat Tube Angle | 74.4 ° | 74.4 ° | 74 ° | 73.6 ° | 73.2 ° |
| Seat Tube Length | 450 mm | 470 mm | 490 mm | 510 mm | 530 mm |
| Head Tube Angle | 70.4 ° | 71.4 ° | 71.8 ° | 72.2 ° | 72.9 ° |
| Head Tube Length | 108 mm | 120 mm | 134 mm | 154 mm | 171 mm |
| Chainstay Length | 413 mm | 413 mm | 411 mm | 411 mm | 411 mm |
| Wheelbase | 983 mm | 989 mm | 990 mm | 997 mm | 1000 mm |
| Bottom Bracket Drop | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm |
| Standover Height | 364 mm | 384 mm | 404 mm | 424 mm | 444 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
About this model
Razor W completes the Vitus Razor model. There are 58 bikes that carry this model name. You can easily view all of the Vitus Razor bikes models from 2022, here.
Model range prices
Vitus Razor W 2022 is the most economical model, with a starting price of 729$. Vitus Razor VR Disc Sora 2022 on the other hand costs 972$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Endurance bikes average price
According to our math, the average price for a trustworthy Endurance bike is 2346$. However, even though the average price of an Endurance bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 729$. In conclusion, this bike price is 221.81% lower than the price of the average Endurance bike.
Endurance bikes average weight
Endurance bikes have an average weight of 8.2 kg (18.08 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Weighing 9 kg (19.84 lbs), the Razor W model is a bit heavier than average. To sum up, it’s 9.76% heavier than the average weight of Endurance bikes.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
When leaving the production line, the Razor W model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Vitus Razor W is equipped with Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they are not nearly as effective as hydraulic brakes are.
