Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork SunTour XCR Air
-
Groupset SLX, Deore -
Suspension Hardtail -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium, Mechanical Formed Triple Butted 6061-T6
Suspension Fork
Suntour XCR Air LO-R-29, Tapered Alloy Steerer, 100mm Travel
Drivetrain
Rear Derailleur
Shimano SLX RD-M675 Shadow Plus
Front Derailleur
Shimano Deore FD-M616, 34.9mm Band
Shift Levers
Shimano SLX SL-M670, Rapid Fire Plus
Cassette
Shimano, 11t-36t, 10-Speed
Crank
FSA Comet MegaExo, 175mm, 38t x 24t
Bottom Bracket
FSA MegaExo (BSA)
Chain
KMC X10, 10-Speed
Wheels
Front Hub
Shimano WH-MT15, Centrelock Disc, QR
Rear Hub
Shimano WH-MT15, Centrelock Disc, QR
Rims
Shimano WH-MT15, 29”
Tires
Continental X-King,, 29” x 2.2”
Brakes
Brakes
Shimano BR-M445 Hydraulic Disc, 180mm Centrelock Rotors
Cockpit
Stem
Vitus Alloy, +/- 7 Degree Rise, 60mm Extension
Handlebar
Vitus Flat Bar, 6061 Double Butted Alloy, 740mm Wide
Headset
FSA Orbit 1.5B, Zero Stack (NO.57B) 1.1/8” - 1.5”
Seat
Saddle
Vitus
Seatpost
Vitus alloy, 6061-T6, 15mm Offset, 31.6mm x 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.53 mm | 1.48 mm | 1.45 mm |
| Bottom Bracket Height | 313 mm | 313 mm | 313 mm |
| Front Center | 662 mm | 681 mm | 698 mm |
| Rake | 46 mm | 46 mm | 46 mm |
| Trail | 87 mm | 87 mm | 87 mm |
| Stack | 616.92 mm | 621.62 mm | 631.01 mm |
| Reach | 404.24 mm | 420.9 mm | 435.2 mm |
| Top Tube Length | 582 mm | 600 mm | 617 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 380 mm | 440 mm | 480 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 105 mm | 110 mm | 120 mm |
| Chainstay Length | 436 mm | 436 mm | 436 mm |
| Wheelbase | 1091 mm | 1109 mm | 1127 mm |
| Bottom Bracket Drop | 61 mm | 61 mm | 61 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
Sentier 290 2014 is a Vitus Sentier model. Vitus launched 75 bikes of this model so far. You can get a glimpse at all models from 2014, by clicking on this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Crosscountry bikes
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Crosscountry bikes average weight
The average weight for Crosscountry bikes is 12.4 kg (27.34 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
Vitus Sentier 290 2014 it’s weighing 13.4 kg (29.54 lbs). At this weight, is a bit heavier than average. In short, the average Crosscountry bike weight is 8.06% lower than this one.
Sentier 290 2014 components
Fork
The SunTour XCR Air is included from the factory. It has a travel distance of 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Fork material
Sentier 290 2014 has an aluminum fork, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels
When leaving the production line, the Sentier 290 2014 model has 29″ aluminum wheels. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
This bike is available in 3 sizes. They vary from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, you won’t have a problem finding one that suits you.
