Vitus Substance VRS-1 Apex 2022
2022 Road
Estimate price |
1,899$
Weight | 10.2 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Apex -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
154cm - 164cm
SM
161cm - 172cm
MD
169cm - 180cm
LG
177cm - 187cm
XL
184cm - 194cm
XXL
192cm - 203cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Substance Aluminium, 6061-T6 Double Butted Aluminium, Internal Cable Routing, 1X Dropper Post Compatible, Mudguard Mounts, Rack Mounts, 12mm x 142mm Hub Spacing, Flat Mount, Axle Specifcations: 160mm Length, 14mm Thread Length, M12xP1.5 Thread Pitch
Suspension Fork
Substance Carbon, UD Carbon, Tapered Steerer, 100 x 12mm, Mudguard Mounts, Flat Mount
Drivetrain
Rear Derailleur
SRAM Apex, 11 Speed, Long Cage
Front Derailleur
N/A, N/A
Shift Levers
SRAM Apex, 11 Speed
Cassette
Sunrace MS8, 11 Speed, 11-42T
Crank
SRAM Apex X-Sync, 40T, 11 Speed, XS:165mm S:170mm M:172.5mm L:172.5mm XL:175mm XXL:175mm
Bottom Bracket
SRAM GXP, BSA Threaded, 68mm, English
Chain
SRAM PC1110, 11 Speed
Wheels
Front Hub
DT Swiss 370, 12x100mm, 6 Bolt
Rear Hub
DT Swiss 370, 142x12mm, 6 Bolt, HG Freehub
Rims
DT Swiss G 1800 Spline, 650b, Tubeless Ready
Tires
Front: WTB Venture TCS Road Plus, 650b x 47, Tubeless Ready, Dual DNA Compound, UST Aramid Bead, Rear: WTB Venture TCS Road Plus, 650b x 47, Tubeless Ready, Dual DNA Compound, UST Aramid Bead
Brakes
Brakes
SRAM Apex, Hydraulic Disc, Flat Mount
Cockpit
Stem
Vitus 6061 Aluminium, 3D Forged, Bar Bore: 31.8mm, +/- 7 degrees, XS:80mm S:80mm M:90mm L:100mm XL:110mm XXL:110mm
Handlebar
Vitus 6061 Aluminium Wing, 77mm Reach, 128mm Drop, 16 Degree Flare, XS:400mm S:400mm M:420mm L:420mm XL:440mm XXL: 440mm
Grips
Vitus Super Grip, Anti Slip, Shockproof
Headset
ACROS Aix-Low R3, Sealed Bearings, OD48, 1 1/8” – 1 ½”, 41.8 / 28.6 – 52 / 40
Seat
Saddle
Vitus, Ti Rail
Seatpost
Vitus 6061 Aluminium, 27.2mm x 350mm, 12mm Offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.45 mm | 1.48 mm | 1.47 mm | 1.49 mm | 1.46 mm |
| Front Center | 591.4 mm | 596.6 mm | 605.1 mm | 617.4 mm | 630.6 mm | 645.2 mm |
| Rake | 48 mm | 48 mm | 48 mm | 48 mm | 48 mm | 48 mm |
| Trail | 63 mm | 59 mm | 58 mm | 58 mm | 61 mm | 60 mm |
| Stack | 541 mm | 558 mm | 575 mm | 584 mm | 602 mm | 613 mm |
| Reach | 378 mm | 384 mm | 389 mm | 398 mm | 405 mm | 419 mm |
| Top Tube Length | 529 mm | 542 mm | 557 mm | 569 mm | 585 mm | 602 mm |
| Seat Tube Angle | 74.2 ° | 74 ° | 73.5 ° | 73.5 ° | 73.2 ° | 73.2 ° |
| Seat Tube Length | 475 mm | 495 mm | 515 mm | 535 mm | 555 mm | 575 mm |
| Head Tube Angle | 70.6 ° | 71.3 ° | 71.5 ° | 71.5 ° | 71.5 ° | 71.75 ° |
| Head Tube Length | 112 mm | 127 mm | 144 mm | 154 mm | 173 mm | 184 mm |
| Chainstay Length | 443 mm | 443 mm | 443 mm | 443 mm | 447 mm | 447 mm |
| Wheelbase | 1024 mm | 1029 mm | 1038 mm | 1050 mm | 1064 mm | 1078 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 765 mm | 782 mm | 801 mm | 814 mm | 832 mm | 847 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 | 650 |
| Rider Min Height | 154 cm | 161 cm | 169 cm | 177 cm | 184 cm | 192 cm |
| Rider Max Height | 164 cm | 172 cm | 180 cm | 187 cm | 194 cm | 203 cm |
Model Overview
Substance VRS-1 Apex is a Vitus Substance model. There are 50 bikes that carry this model name. Take a sneak peek at all Vitus Substance bikes models from 2022, by clicking here.
Model range prices
Vitus Substance 2 Gravel 2022 is the most economical model, with a starting price of 911$. Vitus Substance CRX-1 HT Rival 2022 on the other hand costs 3199$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Gravel bikes average price
If you want an acceptable Gravel bike you should know that the average price is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2022 for 1899$. Comparing the average cost of a Gravel bike to this one, you will see that Substance VRS-1 Apex price is 29.65% lower.
Average weight for Gravel bikes
On a deeper look, we notice that the average weight of a Gravel bike is 8.13 kg (17.92 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
much heavier than average, Substance VRS-1 Apex has a weight of 10.2 kg (22.49 lbs). To sum up, it’s 25.46% heavier than the average weight of Gravel bikes.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
When it comes to wheels, the Substance VRS-1 Apex bike is equipped with the aluminum model. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, if speed is what you’re after, 700c wheels are a better fit.
Brakes
When you want to stop the bike in time, the brakes are vital. The Substance VRS-1 Apex has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
Vitus Substance VRS-1 Apex bike has 6 sizes, in the range of 154 cm – 203 cm (5.05 ft – 6.66 ft). In conclusion, you won’t have a problem finding one that suits you.
