Vitus Substance VRX 2023
2023 Road
Estimate price |
2,302$
Weight | 10.2 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Apex -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
154cm - 164cm
SM
161cm - 172cm
MD
169cm - 180cm
LG
177cm - 187cm
XL
184cm - 194cm
XXL
192cm - 203cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Substance Aluminium, 6061-T6 Double Butted Aluminium, Internal Cable Routing, 1X Dropper Post Compatible, Mudguard Mounts, Rack Mounts, 142 x 12mm Hub Spacing, Flat Mount, Axle Specifcations: 160mm Length, 14mm Thread Length, M12xP1.5 Thread Pitch
Suspension Fork
Substance Carbon, UD Carbon, Tapered Steerer, 100 x 12mm, Mudguard Mounts, Flat Mount, Axle Specifcations: 120mm Length, 14mm Thread Length, M12xP1.5 Thread Pitch
Drivetrain
Rear Derailleur
SRAM Apex, 11 Speed, Long Cage
Front Derailleur
N/A, N/A
Shift Levers
SRAM Apex, 11 Speed
Cassette
Sunrace MS8, 11 Speed, 11-42T
Crank
SRAM Apex X-Sync, 40T, 11 Speed, XS:165mm S:170mm M:172.5mm L:172.5mm XL:175mm XXL:175mm
Bottom Bracket
SRAM GXP, BSA Threaded, 68mm, English
Chain
SRAM PC1110, 11 Speed
Wheels
Front Hub
DT Swiss 370, 12x100mm, 6 Bolt
Rear Hub
DT Swiss 370, 142x12mm, 6 Bolt, HG Freehub
Rims
DT Swiss G 1800 Spline, 650b, Tubeless Ready
Tires
Front: WTB Venture TCS Road Plus, 650b x 47, Tubeless Ready, Dual DNA Compound, UST Aramid Bead, Rear: WTB Venture TCS Road Plus, 650b x 47, Tubeless Ready, Dual DNA Compound, UST Aramid Bead
Brakes
Brakes
SRAM Apex, Hydraulic Disc, Flat Mount
Cockpit
Stem
Vitus 6061 Aluminium, 3D Forged, Bar Bore: 31.8mm, +/- 7 degrees, XS:80mm S:80mm M:90mm L:100mm XL:110mm XXL:110mm
Handlebar
Vitus 6061 Aluminium Wing, 77mm Reach, 128mm Drop, 16 Degree Flare, XS:400mm S:400mm M:420mm L:420mm XL:440mm XXL: 440mm
Grips
Vitus Super Grip, Anti Slip, Shockproof
Headset
ACROS Aix-Low R3, Sealed Bearings, OD48, 1 1/8” – 1 ½”, 41.8 / 28.6 – 52 / 40
Seat
Saddle
Vitus, Steel Rail
Seatpost
Vitus 6061 Aluminium, 27.2mm x 350mm, 12mm Offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.45 mm | 1.48 mm | 1.47 mm | 1.49 mm | 1.46 mm |
| Front Center | 591.4 mm | 596.6 mm | 605.1 mm | 617.4 mm | 630.6 mm | 645.2 mm |
| Rake | 48 mm | 48 mm | 48 mm | 48 mm | 48 mm | 48 mm |
| Trail | 63 mm | 59 mm | 58 mm | 58 mm | 61 mm | 60 mm |
| Stack | 541 mm | 558 mm | 575 mm | 584 mm | 602 mm | 613 mm |
| Reach | 378 mm | 384 mm | 389 mm | 398 mm | 405 mm | 419 mm |
| Top Tube Length | 529 mm | 542 mm | 557 mm | 569 mm | 585 mm | 602 mm |
| Seat Tube Angle | 74.2 ° | 74 ° | 73.5 ° | 73.5 ° | 73.2 ° | 73.2 ° |
| Seat Tube Length | 475 mm | 495 mm | 515 mm | 535 mm | 555 mm | 575 mm |
| Head Tube Angle | 70.6 ° | 71.3 ° | 71.5 ° | 71.5 ° | 71.5 ° | 71.75 ° |
| Head Tube Length | 112 mm | 127 mm | 144 mm | 154 mm | 173 mm | 184 mm |
| Chainstay Length | 443 mm | 443 mm | 443 mm | 443 mm | 447 mm | 447 mm |
| Wheelbase | 1024 mm | 1029 mm | 1038 mm | 1050 mm | 1064 mm | 1078 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 | 650 |
| Rider Min Height | 154 cm | 161 cm | 169 cm | 177 cm | 184 cm | 192 cm |
| Rider Max Height | 164 cm | 172 cm | 180 cm | 187 cm | 194 cm | 203 cm |
Model Overview
Substance VRX is a Vitus Substance model. Vitus released 57 bikes variations of this model so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Vitus Substance V 2023 is the most economical model, with a starting price of 973$. Vitus Substance Carbon HT Rival 2023 on the other hand costs 2999$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Gravel bikes average price
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
At the moment of the release date, Vitus Substance VRX price was 2069$. Doing a quick comparison, we notice that Substance VRX price is 18.99% smaller than the average cost of a Gravel bike.
Gravel bikes average weight
On a deeper look, we notice that the average weight of a Gravel bike is 8.13 kg (17.92 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Vitus Substance VRX it’s weighing 10.2 kg (22.49 lbs). At this weight, is much heavier than average. In conclusion, the average Gravel bike weighs 25.46% less than Substance VRX.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork material
Substance VRX has a carbon fork, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
The Substance VRX 2023 bike is equipped with aluminum wheels when leaving the factory. The 650b wheels are very similar to 700c, with a slight difference in diameter. However, if speed is what you’re after, 700c wheels are a better fit.
Brakes
When you want to stop the bike in time, the brakes are vital. The Substance VRX has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
There are 6 sizes available for this model. Rider height can be anywhere between 154 cm – 203 cm (5.05 ft – 6.66 ft). In conclusion, it won’t take much to find one that’s right for you.
