Vitus Venon EVO-GR Force AXS 2023
2023 Road
Estimate price |
4,899$
Weight | 8 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Force XPLR eTap, Force eTap -
Suspension Rigid -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
160cm - 152cm
SM
167cm - 175cm
MD
172cm - 180cm
LG
177cm - 185cm
XL
182cm - 190cm
XXL
188cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Venon EVO Carbon, SL UD Carbon, Internal Cable Routing, 12mm x 142mm Hub Spacing, Flat Mount, Axle Specifcations: 172mm Length, 14mm Thread Length, M12xP1.5 Thread Pitch
Suspension Fork
Venon EVO Carbon, SL UD Carbon, Tapered Steerer, 100 x 12mm, Flat Mount, Axle Specifcations: 123mm Length, 14mm Thread Length, M12xP1.5 Thread Pitch
Drivetrain
Rear Derailleur
SRAM Force XPLR eTap AXS, 12 Speed
Front Derailleur
N/A
Shift Levers
SRAM Force eTap AXS, 12 Speed
Cassette
SRAM XG 1271 D1 XPLR, 10-44T, 12 Speed
Crank
SRAM Force D1 DUB, 44T, XS:165mm S:170mm M:172.5mm L:172.5mm XL:175mm XXL: 175mm
Bottom Bracket
SRAM DUB BB386, DUB for BB386EVO
Chain
SRAM Force D1, 12 Speed
Wheels
Front Hub
Prime SR1D, 100 x 12mm, Straight Pull, Centre Lock
Rear Hub
Prime SR1D, 142 x 12mm, Straight Pull, Centre Lock, 36T Ratchet System, XD-R Freehub
Rims
Prime Primavera 44 Carbon Disc, Carbon, Tubeless Ready, Disc Brake, Rim Depth: 44mm, Inner Rim Width: 23mm, Outer Rim Width: 30mm
Tires
Front: Michelin Power Gravel TS TLR, 700c x 40c, Tubeless Ready, Rear: Michelin Power Gravel TS TLR, 700c x 40c, Tubeless Ready
Brakes
Brakes
SRAM Force eTap AXS D1 Disc, Hydraulic Disc, Flat Mount
Cockpit
Stem
FSA NS SMR Aluminium, Bar Bore 31.8mm, - 6 degrees, XS:90mm S:100mm M:110mm L:110mm XL:120mm XXL:120mm
Handlebar
Prime Orra Carbon Aero, UD Carbon, Reach: 76.5mm, XS:400mm S:400mm M:420mm L:420mm XL:440mm XXL:440mm
Grips
Vitus Super Grip, Anti Slip
Headset
ZX-1/Venon Specific FSA No.84, Sealed bearing IS52/40 top/bottom, 36deg/45deg
Seat
Saddle
Vitus Race Performance, Ti Rail
Seatpost
Prime Primavera Carbon, 27.2mm, 10mm Offset, XS/S: 300mm M/L: 350mm XL/XXL: 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.43 mm | 1.46 mm | 1.49 mm | 1.52 mm | 1.52 mm |
| Bottom Bracket Height | 278 mm | 279 mm | 279 mm | 279 mm | 279 mm | 279 mm |
| Front Center | 592 mm | 597 mm | 609 mm | 620 mm | 629 mm | 643 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 64 mm | 67 mm | 62 mm | 60 mm | 58 mm | 56 mm |
| Stack | 510 mm | 531 mm | 552 mm | 579 mm | 599 mm | 617 mm |
| Reach | 365 mm | 371 mm | 379 mm | 388 mm | 395 mm | 406 mm |
| Top Tube Length | 507 mm | 523 mm | 543 mm | 563 mm | 581 mm | 597 mm |
| Seat Tube Angle | 74.6 ° | 74.2 ° | 73.8 ° | 73.4 ° | 73 ° | 73 ° |
| Seat Tube Length | 460 mm | 480 mm | mm | 520 mm | 540 mm | 560 mm |
| Head Tube Angle | 70.7 ° | 71.1 ° | 71.5 ° | 72.1 ° | 72.5 ° | 72.7 ° |
| Head Tube Length | 102 mm | 120 mm | 143 mm | 168 mm | 187 mm | 206 mm |
| Chainstay Length | 412 mm | 412 mm | 412 mm | 412 mm | 412 mm | 412 mm |
| Wheelbase | 994 mm | 999 mm | 1012 mm | 1022 mm | 1031 mm | 1045 mm |
| Bottom Bracket Drop | 71 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 160 cm | 167 cm | 172 cm | 177 cm | 182 cm | 188 cm |
| Rider Max Height | 152 cm | 175 cm | 180 cm | 185 cm | 190 cm | 198 cm |
Model Overview
Venon EVO-GR Force AXS is a Vitus Venon model. 32 bikes variations carry this model name so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Vitus Venon EVO-GR Rival 2023 is the most economical model, with a starting price of 3399$. Vitus Venon EVO-RS Force AXS Aero 2023 on the other hand costs 5716$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Gravel bikes average price
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 4899$. In conclusion, this bike price is 98.98% more expensive than the price of the average Gravel bike.
Gravel bikes average weight
Gravel bikes have an average weight of 8.13 kg (17.92 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Venon EVO-GR Force AXS weighs 8 kg (17.64 lbs) and is slightly lighter than the average. In other words, this model is 1.63% lighter than the average Gravel bike.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork material
Venon EVO-GR Force AXS has a carbon fork, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
The Venon EVO-GR Force AXS 2023 bike is equipped with 700c carbon wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
Vitus Venon EVO-GR Force AXS bike has 6 sizes, in the range of 160 cm – 198 cm (5.25 ft – 6.5 ft). In short, it won’t be difficult to find the right one for you.
