Vitus Venon EVO-GR Rival AXS 2023
2023 Road
Estimate price |
4,099$
Weight | 8.3 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Rival XPLR AXS, Rival AXS -
Suspension Rigid -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
160cm - 152cm
SM
167cm - 175cm
MD
172cm - 180cm
LG
177cm - 185cm
XL
182cm - 190cm
XXL
188cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Venon EVO Carbon, SL UD Carbon, Internal Cable Routing, 12mm x 142mm Hub Spacing, Flat Mount, Axle Specifcations: 172mm Length, 14mm Thread Length, M12xP1.5 Thread Pitch
Suspension Fork
Venon EVO Carbon, SL UD Carbon, Tapered Steerer, 100 x 12mm, Flat Mount, Axle Specifcations: 123mm Length, 14mm Thread Length, M12xP1.5 Thread Pitch
Drivetrain
Rear Derailleur
SRAM Rival XPLR eTap AXS, 12 Speed
Front Derailleur
N/A
Shift Levers
SRAM Rival eTap AXS, 12 Speed
Cassette
SRAM XG 1251 D1 XPLR, 10-44T, 12 Speed
Crank
SRAM Rival D1 DUB, 44T, XS:165mm S:170mm M:172.5mm L:172.5mm XL:175mm XXL: 175mm
Bottom Bracket
SRAM DUB BB386, BB386EVO for DUB Spindle
Chain
SRAM Rival D1, 12-Speed
Wheels
Front Hub
Prime SR1D, 100 x 12mm, Straight Pull, Centre Lock
Rear Hub
Prime SR1D, 142 x 12mm, Straight Pull, Centre Lock, 36T Ratchet System, XD-R Freehub
Rims
Prime Primavera 44 Carbon Disc, Carbon, Tubeless Ready, Disc Brake, Rim Depth: 44mm, Inner Rim Width: 23mm, Outer Rim Width: 30mm
Tires
Front: Michelin Power Gravel TS TLR, 700c x 40c, Tubeless Ready, Rear: Michelin Power Gravel TS TLR, 700c x 40c, Tubeless Ready
Brakes
Brakes
SRAM Rival eTap AXS D1 Disc, Hydraulic Disc, Flat Mount
Cockpit
Stem
FSA NS SMR Aluminium, Bar Bore 31.8mm, - 6 degrees, XS:90mm S:100mm M:110mm L:110mm XL:120mm XXL:120mm
Handlebar
Prime Orra Carbon Aero, UD Carbon, Reach: 76.5mm, XS:400mm S:400mm M:420mm L:420mm XL:440mm XXL:440mm
Grips
Vitus Super Grip, Anti Slip
Headset
ZX-1/Venon Specific FSA No.84, Sealed bearing IS52/40 top/bottom, 36deg/45deg
Seat
Saddle
Vitus Race Performance, Ti Rail
Seatpost
Prime Primavera Carbon, 27.2mm, 10mm Offset, XS/S: 300mm M/L: 350mm XL/XXL: 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.43 mm | 1.46 mm | 1.49 mm | 1.52 mm | 1.52 mm |
| Bottom Bracket Height | 278 mm | 279 mm | 279 mm | 279 mm | 279 mm | 279 mm |
| Front Center | 592 mm | 597 mm | 609 mm | 620 mm | 629 mm | 643 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 64 mm | 67 mm | 62 mm | 60 mm | 58 mm | 56 mm |
| Stack | 510 mm | 531 mm | 552 mm | 579 mm | 599 mm | 617 mm |
| Reach | 365 mm | 371 mm | 379 mm | 388 mm | 395 mm | 406 mm |
| Top Tube Length | 507 mm | 523 mm | 543 mm | 563 mm | 581 mm | 597 mm |
| Seat Tube Angle | 74.6 ° | 74.2 ° | 73.8 ° | 73.4 ° | 73 ° | 73 ° |
| Seat Tube Length | 460 mm | 480 mm | mm | 520 mm | 540 mm | 560 mm |
| Head Tube Angle | 70.7 ° | 71.1 ° | 71.5 ° | 72.1 ° | 72.5 ° | 72.7 ° |
| Head Tube Length | 102 mm | 120 mm | 143 mm | 168 mm | 187 mm | 206 mm |
| Chainstay Length | 412 mm | 412 mm | 412 mm | 412 mm | 412 mm | 412 mm |
| Wheelbase | 994 mm | 999 mm | 1012 mm | 1022 mm | 1031 mm | 1045 mm |
| Bottom Bracket Drop | 71 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 160 cm | 167 cm | 172 cm | 177 cm | 182 cm | 188 cm |
| Rider Max Height | 152 cm | 175 cm | 180 cm | 185 cm | 190 cm | 198 cm |
Model Overview
Venon EVO-GR Rival AXS is part of the Vitus Venon model. 32 bikes variations carry this model name so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Vitus Venon EVO-GR Rival 2023 is the most affordable bike of this model and has a price of 3399$. On the other hand, Vitus Venon EVO-RS Force AXS Aero 2023, is the most expensive and costs 5716$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Gravel bikes
If you want to purchase a solid Gravel bike, it is important to know that the average cost is 2462$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When Vitus released this model in 2023, its price was 4099$. Comparing this to the average Gravel bike price, we see that the price is 66.49% more expensive.
Gravel bikes average weight
On a deeper look, we notice that the average weight of a Gravel bike is 8.13 kg (17.92 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
Venon EVO-GR Rival AXS weighs 8.3 kg (18.3 lbs) and is slightly heavier than the average. In other words, this model is 2.09% heavier than the average Gravel bike.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Venon EVO-GR Rival AXS components
Fork material
Venon EVO-GR Rival AXS has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
As for the wheels, Vitus Venon EVO-GR Rival AXS 2023, has a 700c carbon model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Venon EVO-GR Rival AXS has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
There are 6 sizes available for this model. Rider height can be anywhere between 160 cm – 198 cm (5.25 ft – 6.5 ft). In short, you can easily find one that suits you.
