Vitus Venon EVO-RS 105 Di2 2023
2023 Road
Estimate price |
3,899$
Weight | 7.9 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra Di2, 105 Di2 -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
160cm - 152cm
SM
167cm - 175cm
MD
172cm - 180cm
LG
177cm - 185cm
XL
182cm - 190cm
XXL
188cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Venon EVO Carbon, SL UD Carbon, Internal Cable Routing, 12mm x 142mm Hub Spacing, Flat Mount, Axle Specifcations: 172mm Length, 14mm Thread Length, M12xP1.5 Thread Pitch
Suspension Fork
Venon EVO Carbon, SL UD Carbon, Tapered Steerer, 100 x 12mm, Flat Mount, Axle Specifcations: 123mm Length, 14mm Thread Length, M12xP1.5 Thread Pitch
Drivetrain
Rear Derailleur
Shimano 105 R7150, RD-R8150-GS, 12 Speed, Shadow
Front Derailleur
Shimano 105 R7150, FD-R8150, 2 x 12 Speed
Shift Levers
Shimano 105 R7170, Wireless, 12 Speed
Cassette
Shimano CS-HG710-12, 11-34T, 12-Speed
Crank
Shimano 105 7100, 50/34T, XS:165mm S:170mm M:172.5mm L:172.5mm XL:175mm XXL: 175mm
Bottom Bracket
TriPeak BB386, BB386EVO for Shimano 24mm Spindle
Chain
Shimano M7100, 12-Speed
Wheels
Front Hub
Prime SR1, 100 x 12mm, Centre Lock
Rear Hub
Prime SR1, 142 x 12mm, Centre Lock, 36T Ratchet System, HG Freehub
Rims
Prime Attaquer V2, Aluminium, Tubeless Ready, Disc Brake, Rim Depth: 30mm, Inner Rim Width: 19mm, Outer Rim Width: 22mm
Tires
Front: Michelin Power Cup Classic TS TLR, 700c x 28c, Tubeless Ready, Rear: Michelin Power Cup Classic TS TLR, 700c x 28c, Tubeless Ready
Brakes
Brakes
Shimano 105 R7170 Disc, Hydraulic Disc, Flat Mount
Cockpit
Stem
FSA NS SMR Aluminium, Bar Bore 31.8mm, - 6 degrees, XS:90mm S:100mm M:110mm L:110mm XL:120mm XXL:120mm
Handlebar
Prime Doyenne Lightweight Aluminium, Reach: 70mm, XS:380mm S:400mm M:420mm L:420mm XL:440mm XXL:440mm
Grips
Vitus Super Grip, Anti Slip
Headset
ZX-1/Venon Specific FSA No.84, Sealed bearing IS52/40 top/bottom, 36deg/45deg
Seat
Saddle
Vitus Race Performance, Ti Rail
Seatpost
Prime Primavera Carbon, 27.2mm, 10mm Offset, XS/S: 300mm M/L: 350mm XL/XXL: 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.43 mm | 1.46 mm | 1.49 mm | 1.52 mm | 1.52 mm |
| Bottom Bracket Height | 278 mm | 279 mm | 279 mm | 279 mm | 279 mm | 279 mm |
| Front Center | 592 mm | 597 mm | 609 mm | 620 mm | 629 mm | 643 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 64 mm | 67 mm | 62 mm | 60 mm | 58 mm | 56 mm |
| Stack | 510 mm | 531 mm | 552 mm | 579 mm | 599 mm | 617 mm |
| Reach | 365 mm | 371 mm | 379 mm | 388 mm | 395 mm | 406 mm |
| Top Tube Length | 507 mm | 523 mm | 543 mm | 563 mm | 581 mm | 597 mm |
| Seat Tube Angle | 74.6 ° | 74.2 ° | 73.8 ° | 73.4 ° | 73 ° | 73 ° |
| Seat Tube Length | 460 mm | 480 mm | mm | 520 mm | 540 mm | 560 mm |
| Head Tube Angle | 70.7 ° | 71.1 ° | 71.5 ° | 72.1 ° | 72.5 ° | 72.7 ° |
| Head Tube Length | 102 mm | 120 mm | 143 mm | 168 mm | 187 mm | 206 mm |
| Chainstay Length | 412 mm | 412 mm | 412 mm | 412 mm | 412 mm | 412 mm |
| Wheelbase | 994 mm | 999 mm | 1012 mm | 1022 mm | 1031 mm | 1045 mm |
| Bottom Bracket Drop | 71 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 160 cm | 167 cm | 172 cm | 177 cm | 182 cm | 188 cm |
| Rider Max Height | 152 cm | 175 cm | 180 cm | 185 cm | 190 cm | 198 cm |
Model Overview
Venon EVO-RS 105 Di2 completes the Vitus Venon model. There are 32 bikes that carry this model name. You can easily view all of the Vitus Venon bikes models from 2023, here.
Model range prices
Vitus Venon EVO-GR Rival 2023 is the cheapest bike model and costs 3399$. Vitus Venon EVO-RS Force AXS Aero 2023 is the most expensive one and costs 5716$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Gravel bikes average price
According to our calculations, the average cost of a Gravel bike that is reliable is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Vitus released this model in 2023, its price was 3899$. Doing a quick comparison, we notice that Venon EVO-RS 105 Di2 price is 58.37% more expensive than the average cost of a Gravel bike.
Gravel bikes average weight
Gravel bikes weigh an average of 8.13 kg (17.92 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
Weighing 7.9 kg (17.42 lbs), the Venon EVO-RS 105 Di2 model is slightly lighter than average. In short, the average Gravel bike weight is 2.91% higher than this one.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
As for the wheels, Vitus Venon EVO-RS 105 Di2 2023, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Vitus Venon EVO-RS 105 Di2 has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
Vitus Venon EVO-RS 105 Di2 bike has 6 sizes, in the range of 160 cm – 198 cm (5.25 ft – 6.5 ft). In conclusion, it won’t take much to find one that’s right for you.
