Vitus Zenium Tiagra 2022
2022 Road
Estimate price |
1,599$
Weight | 9.3 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Tiagra -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
160cm - 167cm
SM
164cm - 172cm
MD
169cm - 177cm
LG
174cm - 182cm
XL
179cm - 187cm
XXL
184cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Zenium Carbon, T700 UD Carbon, Flat Mount Disc Brake, Internal Cable Routing, 142 x 12mm Hub Spacing, Axle Specifcations: 163mm Length, 14mm Thread Length, M12xP1.5 Thread Pitch
Suspension Fork
Zenium Carbon, UD Carbon, Tapered Carbon Steerer, 100mm x 12mm
Drivetrain
Rear Derailleur
Shimano Tiagra R4700, RD-R4700, 10 Speed
Front Derailleur
Shimano Tiagra R4700, FD-R4700, Braze-On, 2 x 10 Speed
Shift Levers
Shimano Tiagra R4700, ST-R4700-R, 10 Speed
Cassette
Sunrace CS-RX0, 10 Speed, 11-32T
Crank
Shimano Tiagra R4700, 50/34T, 10 Speed, XS:170mm S:170mm M:172.5mm L:172.5mm XL:175mm XXL:175mm
Bottom Bracket
Prestine PF30, PF30 with 24mm adapters
Chain
KMC X10, 10 Speed
Wheels
Front Hub
Vitus KT, TX5F-12, 24h, 12 x 100mm, Centre Lock
Rear Hub
Vitus KT, CRR6L4, 28h, 10/11 Speed, 12 x 142mm, Centre Lock
Rims
Vitus Shining, DB-X21, 700c, 24 Hole,
Tires
Front: Kenda Kwick Roller Sport, 700c x 28c, Rear: Kenda Kwick Roller Sport, 700c x 28c
Brakes
Brakes
TRP Spyre Disc Brake, MD-C610-C, Flat Mount, Cable Actuated
Cockpit
Stem
Vitus 6061 Aluminium, Bar Bore 31.8mm, +/- 7 degrees, XS:90mm S:100mm M:100mm L:110mm XL:110mm XXL:120mm
Handlebar
Vitus 6061 Aluminium, XS:400mm S:400mm M:420mm L:420mm XL:440mm XXL:440mm
Grips
Vitus SuperGrip, Anti Slip, Shockproof
Headset
ACROS Aix 322 R3, Sealed Bearings, OD46, 41.8/28.6 - 47/33, 1 1/8” – 1 ½”, Integrated
Seat
Saddle
Vitus, Steel Rail
Seatpost
Vitus 6061 Aluminium, 27.2mm x 350mm, 12mm Offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.41 mm | 1.43 mm | 1.5 mm | 1.53 mm | 1.56 mm |
| Bottom Bracket Height | 266 mm | 266 mm | 266 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 587.5 mm | 596.2 mm | 604.3 mm | 611.9 mm | 624.3 mm | 630 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 68 mm | 64 mm | 61 mm | 59 mm | 56 mm | 59 mm |
| Stack | 505.2 mm | 523.5 mm | 540 mm | 572.3 mm | 598 mm | 621.8 mm |
| Reach | 364.8 mm | 371 mm | 378 mm | 380.8 mm | 389.9 mm | 399.7 mm |
| Top Tube Length | 506 mm | 523 mm | 540 mm | 557 mm | 574 mm | 591 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 430 mm | 460 mm | 490 mm | 520 mm | 550 mm | 580 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71.5 ° | 72 ° | 72.5 ° |
| Head Tube Length | 110 mm | 130 mm | 150 mm | 175 mm | 200 mm | 225 mm |
| Chainstay Length | 411 mm | 411 mm | 411 mm | 411 mm | 411 mm | 411 mm |
| Wheelbase | 988 mm | 997 mm | 1005 mm | 1013 mm | 1025 mm | 1031 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 717 mm | 741 mm | 763 mm | 793 mm | 820 mm | 846 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 160 cm | 164 cm | 169 cm | 174 cm | 179 cm | 184 cm |
| Rider Max Height | 167 cm | 172 cm | 177 cm | 182 cm | 187 cm | 193 cm |
Model Overview
Zenium Tiagra completes the Vitus Zenium model. Vitus launched 52 bikes of this model so far. Take a sneak peek at all Vitus Zenium bikes models from 2022, by clicking here.
Model range prices
The most economical model, the Vitus Zenium Flat Bar 2022 has a starting price of 1458$. Vitus Zenium CRS Ultegra 2022 on the other hand is the most expensive at 2699$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Race bikes average price
Our math shows that the average cost of a dependable Race bike is 3350$. However, you could also get a good Race bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Vitus released this model in 2022, its price was 1599$. Comparing this to the average Race bike price, we see that the price is 109.51% lower.
Average weight for Race bikes
Race bikes weigh an average of 6.82 kg (15.04 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
With a weight of 9.3 kg (20.5 lbs), Vitus bike is much heavier than average. In conclusion, the average Race bike weighs 36.36% less than Zenium Tiagra.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Zenium Tiagra components
Fork material
When it comes to the fork, this bike has a carbon one, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
As for the wheels, Vitus Zenium Tiagra 2022, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Vitus Zenium Tiagra has Mechanical Disc brakes installed. They are much easier to maintain than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
This bike is available in 6 sizes. They vary from 160 cm – 193 cm (5.25 ft – 6.33 ft). In short, you can easily find one that suits you.
