Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
158cm - 167cm
SM
165cm - 173cm
MD
169cm - 180cm
LG
177cm - 186cm
XL
183cm - 191cm
XXL
186cm - 194cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon T700-HM UD
Suspension Fork
UD Full carbon Tapered
Drivetrain
Rear Derailleur
105 R7000
Front Derailleur
105 R7000
Shift Levers
Shimano 105 ST-R7020
Cassette
CS-R7000 11-30T
Crank
Shimano 105 FC-R7000 52-36T
Bottom Bracket
BB386EVO
Chain
KMC X11-1 with Quick-Link
Wheels
Front Hub
Mavic
Rear Hub
Mavic
Rims
Mavic Cosmic Elite Disc CL
Spokes
Mavic
Tires
Continental Ultrasport II 25c Folding
Brakes
Brakes
Shimano 105 RS-R7020 Hydraulic Flat Mount, 160mm Rotor
Cockpit
Stem
Prime Doyenne Alloy Aero
Handlebar
Prime Doyenne Alloy Aero
Headset
Ritchey Comp
Seat
Saddle
Prologo Dimension
Seatpost
Vitus ZX1 Carbon Aero
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.42 mm | 1.43 mm | 1.42 mm | 1.41 mm | 1.43 mm |
| Bottom Bracket Height | 264 mm | 264 mm | 266 mm | 267 mm | 269 mm | 269 mm |
| Front Center | 568.8 mm | 573.2 mm | 580 mm | 590.9 mm | 608.2 mm | 619.5 mm |
| Rake | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 67 mm | 61 mm | 58 mm | 58 mm | 58 mm | 58 mm |
| Stack | 508 mm | 526 mm | 539.5 mm | 548.5 mm | 561 mm | 579.5 mm |
| Reach | 362 mm | 369.9 mm | 377 mm | 385 mm | 398 mm | 404 mm |
| Top Tube Length | 507 mm | 523 mm | 539 mm | 555 mm | 572 mm | 589 mm |
| Seat Tube Angle | 74.3 ° | 74 ° | 73.5 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 460 mm | 480 mm | 500 mm | 525 mm | 550 mm | 570 mm |
| Head Tube Angle | 71.5 ° | 72.5 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 115 mm | 130 mm | 145 mm | 155 mm | 170 mm | 190 mm |
| Chainstay Length | 402 mm | 402 mm | 402 mm | 402 mm | 402 mm | 402 mm |
| Wheelbase | 959 mm | 964 mm | 971 mm | 983 mm | 1001 mm | 1012 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 70 mm | 69 mm | 67 mm | 67 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 165 cm | 169 cm | 177 cm | 183 cm | 186 cm |
| Rider Max Height | 167 cm | 173 cm | 180 cm | 186 cm | 191 cm | 194 cm |
About this model
ZX-1 CR Aero Disc belongs to the Vitus Zx 1 model. 20 bikes variations carry this model name so far. Take a sneak peek at all Vitus Zx 1 bikes models from 2019, by clicking here.
Model range prices
Vitus ZX-1 CR Aero Disc 2019 is the cheapest bike model and costs 2553$. Vitus ZX-1 CRX Aero Disc 2019 is the most expensive one and costs 5594$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Aero bikes
According to our math, the average price for a trustworthy Aero bike is 4211$. However, you could also get a good Aero bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, this bike was made available in 2019 for 2553$. Comparing the average cost of an Aero bike to this one, you will see that ZX-1 CR Aero Disc price is 64.94% smaller.
ZX-1 CR Aero Disc components
Fork material
The fork on this bike is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
The wheels on ZX-1 CR Aero Disc are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Vitus ZX-1 CR Aero Disc is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
Vitus ZX-1 CR Aero Disc bike has 6 sizes, in the range of 158 cm – 194 cm (5.18 ft – 6.36 ft). In conclusion, it won’t take much to find one that’s right for you.
