Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 29" -
Travel Front 120mm -
Fork RockShox Reba
-
Groupset GX, GX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Reynolds 853 steel
Suspension Fork
Rock Shox REBA RL 120mm Boost; 51mm offset, 29/27.5+"
Drivetrain
Rear Derailleur
SRAM GX - 12-speed EAGLE Rear, LUNAR
Front Derailleur
n/a
Shift Levers
SRAM GX - 12-speed Eagle Rear, Right-hand
Cassette
SRAM XG-1275 12-speed EAGLE, 10-52t
Crank
FC GX EAGLE B148 DUB 175 BLK 32
Bottom Bracket
Truvativ/SRAM DUB BSA MTB73 : BB DUB BSA 73 MTB
Chain
SRAM GX Eagle 12-speed, 114 links
Pedals
Wellgo LU-895DU Mountain Bike Pedals
Wheels
Tires
Maxxis Rekon Front 29: X 2.6", EXO/TR; Agressor Rear 29" X 2.5", EXO/TR
Brakes
Brakes
SRAM Guide RS : DB GDRS GLB FRT 20P 900;
Cockpit
Stem
Race Face Aeffect 35 (Size will change between 50, 60 & 70mm)
Handlebar
Race Face HANDLEBAR,Aeffect,35,10MM RISER, 760MM
Headset
FSA Sealed 1-1/8 ACB Top, 1.5" ACB Btm (for 46/56mm Head Tubes ), alloy crown race (H2166B) Orbit C-40-ACB
Seat
Saddle
WTB Volt Race 142 with Cromo Rails
Seatpost
Race Face Ride XC 27.2mm X 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.61 mm | 1.52 mm | 1.47 mm | 1.44 mm |
| Bottom Bracket Height | 321 mm | 321 mm | 321 mm | 321 mm |
| Front Center | 655 mm | 680.5 mm | 700 | 713.5 mm |
| Stack | 605.8 mm | 610.5 mm | 615.1 mm | 619.8 mm |
| Reach | 377 mm | 400.7 mm | 418.2 mm | 430.25 mm |
| Top Tube Length | 566 mm | 591 mm | 610 mm | 635.4 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 72 ° |
| Seat Tube Length | 343 mm | 368.3 mm | 400 mm | 438.15 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 95 mm | 100 mm | 105 mm | 110 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1085 mm | 1111 mm | 1130 mm | 1143 mm |
| Bottom Bracket Drop | 53 mm | 53 mm | 53 mm | 53 mm |
| Standover Height | 740 mm | 762 mm | 785 mm | 811 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
DAMBALA T2 is a Voodoo Dambala model. There are 6 bikes that carry this model name. Take a sneak peek at all Voodoo Dambala bikes models from 2023, by clicking here.
Model range prices
Voodoo DAMBALA T2 2023 is the cheapest bike model and costs 3606$. Voodoo DAMBALA T0 2023 is the most expensive one and costs 7429$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Trail bikes average price
If you want an acceptable Trail bike you should know that the average price is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
At the moment of the release date, Voodoo DAMBALA T2 price was 3606$. If we compare this with the average Trail bike cost we notice that the price is 30.56% higher.
DAMBALA T2 components
Fork
The fork installed on this bike is the RockShox Reba model. The travel on this model is 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
When it comes to wheels, the DAMBALA T2 bike is equipped with the 29″ model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The DAMBALA T2 comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
Voodoo DAMBALA T2 bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
