Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset Force -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Reynolds 853 Steel
Suspension Fork
Carbon Disc 700c Tapered; 396mm A to C; 100mm X 12mm Thru-Axle
Drivetrain
Rear Derailleur
RD RD FORCE1 LONG CAGE
Front Derailleur
n/a
Shift Levers
DB HRD FRC CX1 ICJ FRONT/LEFT DIR 900mm hose; SB Force Hydraulic Disc, rear caliper, right control, rear shifter,Flat Mount Rear, 1750mm hose, In-Line Connectamajig
Cassette
SRAM PG-1170, 11-32 11-speed
Crank
FC FORCE1 24MM 1725 XSYNC 38
Bottom Bracket
Truvativ/SRAM DUB Threaded BSA 68mm Road
Chain
SRAM PC1170 11-speed, 116 links
Pedals
Wellgo C172DU Road/Hybrid pedal
Wheels
Tires
WTB Raddler 700 X 44 Tan Sidewall, Distance+ Compound, Supple Tubeless Casing, TCS Aramid Bead
Brakes
Brakes
SRAM FORCE 22 - Included above
Cockpit
Stem
Easton EA70 31.8mm Clamp 0 deg 80, 90, 100, 110
Handlebar
Easton EA70 AX 31.8mm Clamp 42, 44, 46 cm
Headset
FSA Sealed 1-1/8 ACB Top, 1.5" ACB Btm (for 46/56mm Head Tubes ), alloy crown race (H2166B) Orbit C-40-ACB
Seat
Saddle
WTB SL8 TEAM with Ti Rails
Seatpost
EA70 SP 0MM 400 27.2 OE
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 50cm | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.56 mm | 1.55 mm | 1.56 mm | 1.55 mm | 1.55 mm | 1.55 mm |
| Bottom Bracket Height | 274 mm | 274 mm | 274 mm | 274 mm | 274 mm | 274 mm |
| Front Center | 567.83 mm | 573.4 mm | 588.7 mm | 609.3 mm | 624.7 mm | 639.6 mm |
| Stack | 530.64 mm | 543.6 mm | 562.5 mm | 581.5 mm | 602.3 mm | 623.3 mm |
| Reach | 340.12 mm | 351.2 mm | 360.2 mm | 374.4 mm | 388.1 mm | 401.6 mm |
| Top Tube Length | 494 mm | 514 mm | 534 mm | 554 mm | 574 mm | 594 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 445 mm | 465 mm | 485 mm | 505 mm | 525 mm | 545 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71 ° | 71 ° | 71.5 ° | 72 ° |
| Head Tube Length | 110 mm | 120 mm | 140 mm | 160 mm | 180 mm | 200 mm |
| Chainstay Length | 419 mm | 419 mm | 419 mm | 419 mm | 419 mm | 419 mm |
| Wheelbase | 975 mm | 981 mm | 1001 mm | 1022 mm | 1037 mm | 1052 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm |
| Standover Height | 748 mm | 761 mm | 780 mm | 799 mm | 819 mm | 839 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
RADA G1 belongs to the Voodoo Rada model. 6 bikes variations carry this model name so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Voodoo RADA G2 2023 is the cheapest bike model and costs 3530$. Voodoo RADA G0 2023 is the most expensive one and costs 6027$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Gravel bikes
If you want an acceptable Gravel bike you should know that the average price is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2023 for 4220$. If we compare this with the average Gravel bike cost we notice that the price is 71.41% higher.
RADA G1 components
Fork material
When it comes to the fork, this bike has a carbon one, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
As for the wheels, Voodoo RADA G1 2023, has a 700c model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The RADA G1 has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Dropper post
Voodoo RADA G1 includes a dropper post. Therefore, climbing or descending will be a breeze.
