Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 80mm -
Fork RST CAPA
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
WHITE XC AL 10S
Suspension Fork
RST Capa 27.5 ML 80mm travel (9x100mm)
Rear Shock
none
Drivetrain
Rear Derailleur
Shimano RDM5120SGS
Front Derailleur
n/a
Shift Levers
Shimano SLM4100R
Cassette
Shimano CSM410010146
Crank
Alloy 32T 165mm
Bottom Bracket
FP-B902
Chain
KMC X10
Pedals
WHITE PP 9/16"
Wheels
Front Hub
Shimano HB-TX505
Rear Hub
Shimano FH-TX505
Rims
WHITE J19Se 32h
Spokes
White spoke
Tires
Kenda K1047 27.5x2.1
Brakes
Brakes
Shimano BL-MT200/BRMT200
Cockpit
Stem
White alloy 31.8mm
Handlebar
White Alloy 660mm
Grips
White grip
Headset
NECO H117A 1-1/8" THREADLESS
Seat
Saddle
WHITE junior
Seatpost
White alloy 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.474 mm | mm | mm | mm | mm |
| Rake | 43 mm | mm | mm | mm | mm |
| Stack | 574.7 mm | mm | mm | mm | mm |
| Reach | 390 mm | mm | mm | mm | mm |
| Top Tube Length | 560.2 mm | mm | mm | mm | mm |
| Seat Tube Angle | 73.5 ° | ° | ° | ° | ° |
| Seat Tube Length | 355 mm | mm | mm | mm | mm |
| Head Tube Angle | 68.8 ° | ° | ° | ° | ° |
| Head Tube Length | 100 mm | mm | mm | mm | mm |
| Chainstay Length | 435 mm | mm | mm | mm | mm |
| Front Travel | 80 mm | mm | mm | mm | mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
XC 275 PRO JR belongs to the White Xc model. 15 bikes variations carry this model name so far. You can easily view all of the White Xc bikes models from 2022, here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Mountain bikes
Our math shows that the average cost of a dependable Mountain bike is 616$. However, even though the average price of a Mountain bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
XC 275 PRO JR components
Fork
This bike has the RST CAPA fork installed. The fork’s travel is 80mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
The wheels on XC 275 PRO JR are the 27.5″ aluminum type. These wheels will provide you with more control over the bike. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. White XC 275 PRO JR is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
White XC 275 PRO JR bike has 5 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
