Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Fork RockShox 35 Gold RL
-
Groupset NX Eagle, X1 -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Alloy, Hydro Formed T6 Aluminium, Multi Butted, SCR, Tapered Headtube, Internal Cable Routing with BBX63, Chainstay Post Mount Dropouts and 12mm X 148mm Boost Dropouts
Suspension Fork
RockShox 35 Gold RL 29"", 120mm Travel, 44mm Offset, DebonAir, Fast Black Coating, Adjustable Compression and Rebound, Tapered Steerer, 110mm x 15mm Boost, Maxle Lite
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM NX Eagle, 12 Speed
Front Derailleur
N/A
Shift Levers
SRAM NX Eagle, MMX, 12 Speed
Cassette
SRAM PG-1210 Eagle, 11-50, 12 Speed
Crank
SRAM X1 Eagle, X-SYNC 2, Direct Mount 32T, DUB, 170mm, Boost 12 Speed
Bottom Bracket
SRAM DUB, BSA, 73mm
Chain
SRAM NX Eagle, 12 Speed
Pedals
Fibre Reinforced Composite Platform
Wheels
Front Hub
Alloy, Double Sealed Cartridge Bearings, 15mm x 110mm Boost Thru Axle, 31mm Torque Caps, 32 Hole
Rear Hub
Alloy, Double Sealed Cartridge Bearings, 12mm x 148mm Boost Thru Axle, 32 Hole
Rims
WTB ST i27 TCS 2.0 System, Pinned Joint, Tubeless Ready, 32 Hole
Spokes
DT Swiss New Champion 2.0mm, Black Stainless, Brass Nipples
Tires
Maxxis High Roller II TR 29"" x 2.3"" 3C MaxxTerra Exo Front, Maxxis Forecaster 29"" x 2.35"" Exo Dual compound Rear
Brakes
Brakes
SRAM Guide T, 4 Piston, 180mm Disc
Brake Levers
SRAM Guide T, Matchmaker
Cockpit
Stem
Whyte Alloy, 45mm Extension
Handlebar
Whyte 6061 Alloy, 15mm Rise, 31.8mm, 780mm Wide
Grips
Whyte Lock-on Enduro Grip
Headset
FSA No. 57B Orbit ZS, 1 1/2"" Lower and 1 1/8"" Upper Caged Bearings
Seat
Saddle
Whyte Custom
Seatpost
Whyte Drop.it, 30.9mm, M 150mm, L/XL 170mm Travel, South Paw MMX Remote Lever
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Bottom Bracket Height | 300 mm | 300 mm | 300 mm |
| Front Center | 775 mm | 800 mm | 829 mm |
| Stack | 637 mm | 641 mm | 655 mm |
| Top Tube Length | 636 mm | 660 mm | 687 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 431 mm | 457 mm | 483 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 115 mm | 120 mm | 135 mm |
| Chainstay Length | 447 mm | 447 mm | 447 mm |
| Wheelbase | 1212 mm | 1237 mm | 1267 mm |
| Bottom Bracket Drop | 74 mm | 74 mm | 74 mm |
| Standover Height | 802 mm | 816 mm | 835 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
Model Overview
629 completes the Whyte 629 model. Whyte released 10 bikes variations of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Whyte 629 Trail Hardtail Bike 2023 is the most affordable bike of this model and has a price of 2434$. On the other hand, Whyte 629 2023, is the most expensive and costs 2434$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Trail bikes
According to our math, the average price for a trustworthy Trail bike is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2023 for 2434$. If we compare this with the average Trail bike cost we notice that the price is 13.48% smaller.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork
The fork installed on this bike is the RockShox 35 Gold RL model. The travel on this model is 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
The 629 2023 bike is equipped with 29″ aluminum wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
When you want to stop the bike in time, the brakes are vital. The 629 has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
629 comes in 3 sizes, that range from 165 cm – 198 cm (5.41 ft – 6.5 ft). In short, you can easily find one that suits you.
Dropper post
Whyte 629 comes with a dropper post. Therefore, climbing or descending will be a breeze.
