Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Groupset XT, Zee -
Suspension Rigid -
Battery 418Wh -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Hydro Formed T6 Aluminium, Tapered Head Tube, Hydro Formed Down Tube, Custom Drawn, Multi Butted with Custom Whyte Dropouts and Kick Stand Mount
Suspension Fork
Whyte Straight Bladed 6061 Alloy, Flat Mount, Single Eyelets for Mudguards and Internal Cable Routing
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano RD-M781, Deore XT, SGS 10-Speed, Shadow
Front Derailleur
N/A
Shift Levers
Shimano SL-M640, Zee, 10 Speed with STEPS SC-E5000 Display
Cassette
Sunrace CSMS1, 11-36, 10 Speed
Crank
Whyte Forged 44T with Double Sided Chain Guard, 165mm, 10 Speed
Bottom Bracket
N/A
Chain
KMC e10T, e-bike specific chain with EPT Anti-Rust, 10 Speed
Pedals
Fibre Reinforced Composite Platform
Wheels
Front Hub
Alloy, Double Sealed Cartridge Bearings, 32 Hole
Rear Hub
Alloy, Double Sealed Cartridge Bearings, 32 Hole
Rims
WTB STp i23 650b Rims with TCS System, Pinned Joint, Tubeless Ready, 32 Hole
Spokes
2.0mm, Black Stainless with Brass Nipples
Tires
WTB Byway, Tan Wall, 650 x 47c
Brakes
Brakes
Tektro Auriga, 160mm Disc, Flat Mount, Internal Routing
Brake Levers
Tektro Auriga
Cockpit
Stem
Whyte Alloy 6061, M 70mm, L 80mm, XL 90mm
Handlebar
Whyte Alloy 6061, 31.8mm, 25mm Rise, 620mm Wide
Grips
Whyte Custom Dual Density Lock-on
Headset
FSA No. 42 B CUP for 1 1/2" Lower and 1 1/8" Upper
Seat
Saddle
Whyte Custom, Triple Panel Design
Seatpost
Whyte 6061 Alloy, 1pcs 3D Forged, 20mm Offset, 27.2mm x 350mm, 2 Bolt Clamp
Motor & Battery
Battery
418Wh
Remote
SC-E5000
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Bottom Bracket Height | 265 mm | 265 mm | 265 mm |
| Top Tube Length | 594.3 mm | 608.3 mm | 628.3 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 445.3 mm | 495.3 mm | 533.4 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 165 mm | 185 mm | 205 mm |
| Chainstay Length | 444 mm | 444 mm | 444 mm |
| Wheelbase | 1089 mm | 1104 mm | 1119 mm |
| Standover Height | 749 mm | 785 mm | 816 mm |
| Wheels | 650 | 650 | 650 |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
About this model
CLIFTON is part of the Whyte E Clifton model. Whyte released 4 e-bikes variations of this model so far. You can easily view all of the Whyte E Clifton e-bikes models from 2022, here.
Model range prices
The most economical model, the Whyte Clifton e-Commuter 2022 has a starting price of 3405$. Whyte Clifton Electric Commuter Bike 2022 on the other hand is the most expensive at 3526$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Hybrid e-bikes average price
According to our math, the average price for a trustworthy Hybrid e-bike is 2480$. However, this doesn’t mean that if you spend less money on a Hybrid e-bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
Furthermore, this bike was made available in 2022 for 3405$. If we compare this with the average Hybrid e-bike cost we notice that the price is 37.3% higher.
CLIFTON components
Fork material
The fork is made out of aluminum, which doesn’t add too much extra weight to the e-bike. However, it is not so stiff as steel or carbon forks are.
Wheels
As for the wheels, Whyte CLIFTON 2022, has a aluminum model. The 650b wheels are very similar to 700c, with a slight difference in diameter. However, if speed is what you’re after, 700c wheels are a better fit.
Brakes
Nothing is more important on a bike than its ability to brake properly. Whyte CLIFTON is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
Whyte CLIFTON e-bike has 3 sizes, in the range of 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, you won’t have a problem finding one that suits you.
