Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 160mm -
Fork Fox Performance Float 38
-
Groupset X01 Eagle, GX -
Suspension Full -
Motor Bosch 250W 85Nm mid-drive -
Battery Bosch 625 Wh internal PowerTube. Reaches full charge in 5 hours with supplied 4A Compact Charger, 80% charge from 0 in 2.5 hours -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Alloy, Hydro Formed T6 Aluminium, Multi Butted, Custom Drawn, Tapered Headtube, Internal Cable Routing for Dropper Post and 12mm X 148mm Boost Dropouts
Suspension Fork
Fox Float 38, Performance 27.5", 160mm Travel, 44mm Offset with Grip Damper, 3pos Adjust and custom tune, Tapered Steerer, 110mm x 15mm Boost, E-Thru Axle
Rear Shock
Fox Float Performance DPS, Evol LV, 3pos adjustable Compression and Rebound damping
Drivetrain
Rear Derailleur
SRAM X01 Eagle, 12 Speed
Front Derailleur
N/A
Shift Levers
SRAM GX-E Eagle, Single Click, MMX, 12 Speed
Cassette
SRAM XG-1275 Eagle, 10-52, 12 Speed
Crank
SRAM EX1, 165mm, ISIS with X-SYNC 2, Direct Mount 34T for Bosch Gen 4, Black
Bottom Bracket
N/A
Chain
SRAM GX Eagle, 12 Speed
Pedals
None
Wheels
Front Hub
Alloy, Double Sealed Cartridge Bearings, 15mm x 110mm Boost Through Axle, 32 Hole
Rear Hub
Alloy, e-bike specific, Double Sealed Cartridge Bearings, 12mm x 148mm Boost Through Axle, 32 Hole
Rims
WTB HTZ i30 TCS 2.0 System, Asymmetric, Sleeved Joint, Super Tough Construction, Tubeless Ready, 32 Hole
Spokes
DT Swiss Champion 2.0mm, Black Stainless, Brass Nipples
Tires
Maxxis Assegai WT, TR, 27.5" x 2.5" 120TPI, EXO+ casing, 3C Maxx Terra, Dual Compound, Front, Maxxis Minion DHR WT, TR, 27.5" x 2.4" 120TPI, Double Down, 3C Maxx Terra, Dual Compound, Folding Bead, Rear
Brakes
Brakes
SRAM Code R, 4 Piston with Sintered Metal Pads, 220mm Disc
Brake Levers
SRAM Code R, MMX
Cockpit
Stem
Whyte Enduro Stem, 35mm Bar Bore, 35mm Extension
Handlebar
Whyte Custom 6061 Alloy, 30mm Rise, 35mm Bar Bore, 780mm Wide
Grips
Whyte Lock-on V Grip
Headset
FSA No. 57E Orbit ZS, 1 1/2" Lower and 1 1/8" Upper Sealed Cartridge Bearings
Seat
Saddle
Whyte Custom, Triple Panel Design
Seatpost
Crank Bro High-Line 3, 30.9mm, XS/S 125mm Travel, M/L 150mm XL 170mm Travel, High-Line Ball Socket Remote Lever
Motor & Battery
Motor
Bosch Performance Line CX (Gen 4). 85 Nm max Torque, 250 W nominal power, 2.79 kg 4 Power settings including progressive eMTB mode which automatically adjusts the support
Battery
Bosch 625 Wh internal PowerTube. Reaches full charge in 5 hours with supplied 4A Compact Charger, 80% charge from 0 in 2.5 hours
Remote
Bosch Purion
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.41 mm | 1.36 mm | 1.31 mm | 1.27 mm |
| Bottom Bracket Height | 330 mm | 330 mm | 330 mm | 330 mm | 330 mm |
| Stack | 600.4 mm | 609.6 mm | 622.3 mm | 633.2 mm | 645 mm |
| Reach | 412.3 mm | 432.3 mm | 457.3 mm | 482.3 mm | 507.3 mm |
| Top Tube Length | 560 mm | 581.5 mm | 611.4 mm | 640.6 mm | 670.1 mm |
| Seat Tube Angle | 75.4 ° | 75.2 ° | 75 ° | 74.8 ° | 74.6 ° |
| Seat Tube Length | 368.3 mm | 406.4 mm | 431.8 mm | 457.2 mm | 482.6 mm |
| Head Tube Angle | 64 ° | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 112 mm | 116 mm | 130 mm | 142 mm | 155 mm |
| Chainstay Length | 444 mm | 444 mm | 444 mm | 444 mm | 444 mm |
| Wheelbase | 1188 mm | 1199 mm | 1230 mm | 1260 mm | 1291 mm |
| Bottom Bracket Drop | 25 mm | 25 mm | 25 mm | 25 mm | 25 mm |
| Standover Height | 794 mm | 809 mm | 824 mm | 824 mm | 826 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
E-160 RS v1 is part of the Whyte E E 160 model. 14 e-bikes variations carry this model name so far. Check out the entire range from 2021 of this model, by clicking this link.
Model range prices
The most economical model, the Whyte E-160 S YOUTH v1 2021 has a starting price of 6325$. Whyte E-160 RS v1 2021 on the other hand is the most expensive at 7116$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Enduro e-bikes average price
If you want to purchase a solid Enduro e-bike, it is important to know that the average cost is 4785$. However, even though the average price of an Enduro e-bike is lower, you might still be able to get a top-quality e-bike. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
This e-bike was released in 2021 and its price was 7116$. Comparing the average cost of an Enduro e-bike to this one, you will see that E-160 RS v1 price is 48.71% more expensive.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
E-160 RS v1 components
Fork
Whyte E-160 RS v1 2021 e-bike is equipped with the Fox Performance Float 38 fork, and has 160mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
When leaving the production line, the E-160 RS v1 model has 27.5″ aluminum wheels. The 27.5″ wheels are a great choice for smaller riders. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Whyte E-160 RS v1 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
Whyte E-160 RS v1 e-bike has 5 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Whyte E-160 RS v1 comes with a dropper post. Therefore, climbing or descending will be a breeze.
