Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 180mm -
Fork Fox Factory Float 38
-
Groupset X01 Eagle, Race Face -
Suspension Full -
Motor Bosch 250W 85Nm mid-drive -
Battery Bosch 625 Wh internal PowerTube. Reaches full charge in 5 hours with supplied 4A Compact Charger, 80% charge from 0 in 2.5 hours -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Alloy, Hydro Formed T6 Aluminium, Multi Butted, Custom Drawn, Tapered Headtube, Internal Cable Routing for Dropper Post and 12mm X 148mm Boost Dropouts
Suspension Fork
Fox Float 38, Factory 27.5", 180mm Travel, 44mm Offset with Grip 2 Damper and custom tune, Tapered Steerer, Kashima Coating, 110mm x 15mm Boost, E-Thru Axle
Rear Shock
Fox Float X2, Factory, independently adjustable Compression and Rebound damping, Kashima coating
Drivetrain
Rear Derailleur
SRAM X01 Eagle, 12 Speed
Front Derailleur
N/A
Shift Levers
SRAM X01-E Eagle, Single Click, MMX, 12 Speed
Cassette
SRAM XG-1275 Eagle, 10-52, 12 Speed
Crank
Race Face Affect E-Bike, 165mm, ISIS with X-SYNC Direct Mount 34T for Bosch Gen 4, Black
Bottom Bracket
N/A
Chain
SRAM GX Eagle, 12 Speed
Pedals
None
Wheels
Front Hub
DT Swiss 350, 15mm x 110mm, Centre-Lock, 28 Hole
Rear Hub
DT Swiss 350 Straightpull with 24T Ratchet System, 12mm x 148mm, 6 Bolt with Magnet carrier, 28 Hole
Rims
DT Swiss Hybrid 30, Sleeved Joint, 28 Hole
Spokes
DT Swiss Hybrid triple butted 2.34mm/1.8mm/2.0mm, Black Stainless, DT Pro Lock Squorx Nipples
Tires
Maxxis Assegai WT, TR, 27.5" x 2.5" 120TPI, EXO + Sidewall Protection, 3C Maxx Terra, Dual Compound, Folding Bead, Front, Maxxis Assegai WT, TR, 27.5" x 2.5" 120TPI, Double Down casing, 3C Maxx Terra, Dual Compound, Rear
Brakes
Brakes
SRAM Code RSC, 4 Piston with Sintered Metal Pads, 220mm Disc
Brake Levers
SRAM Code RSC, MMX
Cockpit
Stem
Race Face Atlas, 35mm Bar Bore, 35mm Extension
Handlebar
Race Face Turbine R, 35mm Rise, 35mm Bar Bore, 800mm Wide
Grips
Whyte Lock-on V Grip
Headset
FSA No. 57E Orbit ZS, 1 1/2" Lower and 1 1/8" Upper Sealed Cartridge Bearings
Seat
Saddle
Whyte Custom, Triple Panel Design
Seatpost
Crank Bro High-Line 3, 30.9mm, M/L 150mm Travel, XL 170mm Travel, High-Line Ball Socket Remote Lever
Motor & Battery
Motor
Bosch Performance Line CX (Gen 4). 85 Nm max Torque, 250 W nominal power, 2.79 kg 4 Power settings including progressive eMTB mode which automatically adjusts the support
Battery
Bosch 625 Wh internal PowerTube. Reaches full charge in 5 hours with supplied 4A Compact Charger, 80% charge from 0 in 2.5 hours
Remote
Bosch Purion
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.32 mm | 1.29 mm |
| Bottom Bracket Height | 335 mm | 335 mm | 335 mm |
| Stack | 624.1 mm | 633 mm | 646.5 mm |
| Reach | 452.8 mm | 477.8 mm | 502.8 mm |
| Top Tube Length | 602.8 mm | 630.8 mm | 660.8 mm |
| Seat Tube Angle | 75.5 ° | 75.3 ° | 75.1 ° |
| Seat Tube Length | 431.8 mm | 457.2 mm | 482.5 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 120 mm | 130 mm | 145 mm |
| Chainstay Length | 441 mm | 441 mm | 441 mm |
| Wheelbase | 1239 mm | 1267 mm | 1299 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 20 mm |
| Standover Height | 838 mm | 838 mm | 838 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
Model Overview
E-180 RS v2 is a Whyte E E 180 model. 11 e-bikes variations carry this model name so far. You can easily view all of the Whyte E E 180 e-bikes models from 2021, here.
Model range prices
Whyte E-180 S v2 2021 is the most affordable e-bike of this model and has a price of 6690$. On the other hand, Whyte E-180 RS v2 2021, is the most expensive and costs 8393$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Enduro e-bikes
According to our math, the average price for a trustworthy Enduro e-bike is 4785$. However, even though the average price of an Enduro e-bike is lower, you might still be able to get a top-quality e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Whyte E-180 RS v2 price was 8393$. If we compare this with the average Enduro e-bike cost we notice that the price is 75.4% more expensive.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork
This e-bike has the Fox Factory Float 38 fork installed. The fork’s travel is 180mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
The E-180 RS v2 2021 e-bike is equipped with 27.5″ aluminum wheels when leaving the factory. The 27.5″ wheels are a great choice for smaller riders. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Whyte E-180 RS v2 has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
This e-bike is available in 3 sizes. They vary from 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
The Whyte model is also equipped with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
