Whyte E-504 Compact Hardtail Electric Mountain Bike 2022
2022 E-bike
Estimate price |
4,683$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Fork RockShox 35 Silver
-
Groupset GX -
Suspension Hardtail -
Motor 85Nm mid-drive -
Battery 500Wh -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
160cm - 172cm
MD
166cm - 179cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Alloy, Hydro Formed T6 Aluminium, Multi Butted, Custom Drawn, Tapered Headtube, Internal Cable Routing for Dropper Post and 12mm X 148mm Boost Dropouts
Suspension Fork
RockShox 35 Silver TK 27.5", 120mm Travel, 37mm Offset, DebonAir, Fast Black Coating, Adjustable Compression and Rebound, Tapered Steerer, 110mm x 15mm Boost, Maxle Lite
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM GX, 11 Speed
Front Derailleur
N/A
Shift Levers
SRAM GX, 11 Speed
Cassette
SRAM PG-1130, 11-42, 11 Speed
Crank
Whyte, Steel narrow/wide, 165mm, Direct Mount 36T for Bosch Performance Line CX, Black
Bottom Bracket
N/A
Chain
KMC NPBK Sport, 11 Speed
Pedals
None
Wheels
Front Hub
Alloy, Double Sealed Cartridge Bearings, 15mm x 110mm Boost Thru Axle, 31mm Torque Caps, 32 Hole
Rear Hub
Alloy, e-bike specific, Double Sealed Cartridge Bearings, 12mm x 148mm Boost Thru Axle, 32 Hole
Rims
WTB ST i30 TCS 2.0 System, Pinned Joint, Tubeless Ready, 32 Hole
Spokes
DT Swiss Champion 2.0mm, Black Stainless, Brass Nipples
Tires
Maxxis Forekaster TR 27.5" x 2.6" 60TPI, EXO Sidewall Protection
Brakes
Brakes
Tektro Orion, 4-Piston with Sintered Metal Pads, 200mm Disc, Post Mount
Brake Levers
Tektro Orion
Cockpit
Stem
Whyte Alloy 6061, 35mm Extension
Handlebar
Whyte 6061 Alloy, XS and S 15mm Rise, 31.8mm, 760mm, M 30mm Rise, 31.8mm, 780mm Wide
Grips
Whyte Lock-on V Grip
Headset
FSA No. 57B Orbit ZS, 1 1/2" Lower and 1 1/8" Upper Caged Bearings
Seat
Saddle
Whyte Custom, Triple Panel Design
Seatpost
Whyte drop.it, 30.9, XS 100mm, S 125mm, M 150mm Travel, Paddle Remote Lever
Motor & Battery
Motor
Performance CX 85Nm
Battery
500Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD |
|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.45 mm | 1.36 mm |
| Bottom Bracket Height | 305 mm | 305 mm | 305 mm |
| Stack | 598 mm | 608 mm | 608 mm |
| Reach | 401 mm | 419 mm | 448 mm |
| Top Tube Length | 567 mm | 588 mm | 618 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 381 mm | 406 mm | 444 mm |
| Head Tube Angle | 64 ° | 64.5 ° | 64.5 ° |
| Head Tube Length | 107 mm | 115 mm | 115 mm |
| Chainstay Length | 438 mm | 438 mm | 438 mm |
| Wheelbase | 1144 mm | 1161 mm | 1191 mm |
| Bottom Bracket Drop | 50 mm | 50 mm | 50 mm |
| Standover Height | 710 mm | 726 mm | 756 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 151 cm | 160 cm | 166 cm |
| Rider Max Height | 164 cm | 172 cm | 179 cm |
About this model
E-504 Compact Hardtail Electric Mountain Bike is a Whyte E E 504 model. Whyte launched 2 e-bikes of this model so far. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
The most economical model, the Whyte E-504 Compact Hardtail Electric Mountain Bike 2022 has a starting price of 4256$. Whyte E-504 2022 on the other hand is the most expensive at 4378$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail e-bikes
According to our math, the average price for a trustworthy Trail e-bike is 3365$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail e-bike. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
When Whyte released this model in 2022, its price was 4256$. Comparing the average cost of a Trail e-bike to this one, you will see that E-504 Compact Hardtail Electric Mountain Bike price is 26.48% more expensive.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork
Whyte E-504 Compact Hardtail Electric Mountain Bike 2022 e-bike is equipped with the RockShox 35 Silver fork, and has 120mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
When it comes to wheels, the E-504 Compact Hardtail Electric Mountain Bike e-bike is equipped with the 27.5″ aluminum model. These wheels will provide you with more control over the e-bike. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The E-504 Compact Hardtail Electric Mountain Bike comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
This e-bike is available in 3 sizes. They vary from 151 cm – 179 cm (4.95 ft – 5.87 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
The Whyte model is also equipped with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
