Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Groupset XT, Zee -
Suspension Rigid -
Motor Shimano 250W 60Nm mid-drive -
Battery 418Wh -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Hydro Formed T6 Aluminium, Tapered Head Tube, Hydro Formed Down Tube, Custom Drawn, Multi Butted with Custom Whyte Dropouts and Kick Stand mount
Suspension Fork
Whyte Straight Bladed 6061 Alloy, Flat Mount, Single Eyelets for Mudguards and Internal Cable RoutBicyclesing
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano RD-M781, Deore XT, SGS 10-Speed, Shadow
Front Derailleur
N/A
Shift Levers
Shimano SL-M640, Zee, 10 Speed with STEPS SC-E5000 Display
Cassette
Sunrace CSMS1, 11-36, 10 Speed
Bottom Bracket
N/A
Chain
KMC e10T, e-bike specific chain with EPT Anti-Rust, 10 Speed
Pedals
Fibre Reinforced Composite Platform
Wheels
Front Hub
Alloy, Double Sealed Cartridge Bearings, 32 Hole
Rear Hub
Alloy, Double Sealed Cartridge Bearings, 32 Hole
Rims
WTB STp i23 650b Rims with TCS System, Pinned Joint, Tubeless Ready, 32 Hole
Spokes
2.0mm, Black Stainless with Brass Nipples
Tires
WTB Byway, Tan Wall, 650 x 47c
Brakes
Brakes
Tektro Auriga, 160mm Disc, Flat Mount, Internal Routing
Brake Levers
Tektro Auriga
Cockpit
Stem
Whyte Alloy 6061, S 60mm, M 70mm, L 80mm
Handlebar
Whyte 6061 Alloy, 20mm Rise, 31.8mm, 620mm Wide
Grips
Whyte Custom Dual Density Lock-on
Headset
FSA No. 42 B CUP for 1 1/2" Lower and 1 1/8" Upper
Seat
Saddle
Whyte Custom
Seatpost
Whyte Suspension 6061 Alloy, 12mm Offset, 30.9mm, 2 Bolt Clamp
Motor & Battery
Motor
E6100 60Nm
Battery
418Wh
Remote
SC-E5000
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Bottom Bracket Height | 265 mm | 265 mm | 265 mm |
| Top Tube Length | 546.7 mm | 572.7 mm | 598.7 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° |
| Seat Tube Length | 393.7 mm | 431.8 mm | 469.9 mm |
| Head Tube Angle | 69 ° | 69.5 ° | 70 ° |
| Head Tube Length | 140 mm | 160 mm | 180 mm |
| Chainstay Length | 443 mm | 443 mm | 443 mm |
| Wheelbase | 1060 mm | 1071 mm | 1088 mm |
| Standover Height | 713 mm | 734 mm | 767 mm |
| Wheels | 650 | 650 | 650 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
HIGHGATE completes the Whyte E Highgate model. 4 e-bikes variations carry this model name so far. Take a sneak peek at all Whyte E Highgate e-bikes models from 2022, by clicking here.
Model range prices
The most economical model, the Whyte Highgate e-Commuter 2022 has a starting price of 3405$. Whyte Highgate Compact Electric Commuter Bike 2022 on the other hand is the most expensive at 3526$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Hybrid e-bikes
According to our calculations, the average cost of a Hybrid e-bike that is reliable is 2480$. However, even if your budget is less than the average, you might still be able to get a top-quality Hybrid e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
At the moment of the release date, Whyte HIGHGATE price was 3405$. Doing a quick comparison, we notice that HIGHGATE price is 37.3% higher than the average cost of a Hybrid e-bike.
HIGHGATE components
Fork material
HIGHGATE has an aluminum fork, which doesn’t add too much extra weight to the e-bike. However, it is not so stiff as steel or carbon forks are.
Wheels
The HIGHGATE 2022 e-bike is equipped with aluminum wheels when leaving the factory. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, if speed is what you’re after, 700c wheels are a better fit.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The HIGHGATE comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
This e-bike is available in 3 sizes. They vary from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, you won’t have a problem finding one that suits you.
