Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 120mm -
Fork RockShox SID
-
Groupset XX1 Eagle AXS, X01 Eagle AXS -
Suspension Full -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon, Uni-directional Multi Monocoque Front Triangle with Internal Cable Routing, Tapered Head Tube and Intergrip Seat Clamp System, ISCG, 2 Bolt Guide Mounts, Alloy Symmetrical SCR Rear Triangle, 148mm Boost Dropouts
Suspension Fork
RockShox SID 35 Ultimate 29", 120mm Travel, 44mm Offset, DebonAir, Charger Race Day Damper, Fast Black Coating, Tapered Steerer, 110mm x 15mm Boost, Maxle Ultimate
Rear Shock
RockShox SIDLuxe Ultimate RL, DebonAir, Fast Black Coating, Adjustable Rebound and 2 Position Compression
Drivetrain
Rear Derailleur
SRAM XX1 AXS Eagle, 12 Speed
Front Derailleur
N/A
Shift Levers
SRAM AXS Eagle, MMX Clamp, 12 Speed
Cassette
SRAM XG-1299 X-DOME Eagle, 10-52, Copper, 12 Speed
Crank
SRAM XX1 Carbon Eagle, X-SYNC 2, Direct Mount 34T, DUB, 175mm, 12 Speed
Bottom Bracket
SRAM DUB, BSA, 73mm
Chain
SRAM XX1 Eagle, Copper, 12 Speed
Pedals
None
Wheels
Front Hub
Hope Pro 4, Sealed Stainless Steel Cartridge Bearings, 15mm x 110mm Boost Through Axle, 28 Hole
Rear Hub
Hope Pro 4, Sealed Stainless Steel Cartridge Bearings, 12mm x 148mm Boost Through Axle, 28 Hole
Rims
Whyte 30mm Carbon Hookless, Offset, Tubeless Ready, TeXtreme® Inegra Blast Skin, 3M Rim Strip with Tubeless Valves included, 28 Hole
Spokes
DT Swiss Competition Butted 2.0-1.8-2.0mm, Black Stainless, Brass Nipples
Tires
Maxxis Forekaster TR 29" x 2.35" 120TPI 3C Maxx Speed, EXO Sidewall Protection, Front, Maxxis Ardent Race TR 29" x 2.35" 120TPI Maxx Speed, EXO Sidewall Protection, Rear
Brakes
Brakes
SRAM Guide G2 Ultimate, 4 Piston, 180mm Disc
Brake Levers
SRAM Guide G2 Ultimate, MMX
Cockpit
Stem
Whyte Gravity Stem, 35mm Bar Bore, 40mm Extension
Handlebar
Race Face NEXT R Carbon, 10mm Rise, 35mm Bar Bore, 800mm Wide
Grips
Whyte Lock-on V Grip
Headset
FSA No. 42 Orbit ZS Plus, Integrated, 1 1/2" Lower and 1 1/8" Upper Sealed Cartridge Bearings
Seat
Saddle
Whyte Custom Team, with Lightweight Foam, CrMo Rails, Triple Panel Design
Seatpost
SRAM Reverb AXS, 30.9mm, M/L 150mm Travel, XL 170mm Travel
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.31 mm | 1.27 mm |
| Bottom Bracket Height | 335 mm | 335 mm | 335 mm |
| Stack | 613.8 mm | 624.8 mm | 636.8 mm |
| Reach | 453.8 mm | 477.8 mm | 501.8 mm |
| Top Tube Length | 580.8 mm | 637.8 mm | 666.8 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 431.8 mm | 457.2 mm | 482.6 mm |
| Head Tube Angle | 65.6 ° | 65.6 ° | 65.6 ° |
| Head Tube Length | 125 mm | 140 mm | 150 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1195 mm | 1224 mm | 1253 mm |
| Bottom Bracket Drop | 39 mm | 39 mm | 39 mm |
| Standover Height | 799 mm | 805 mm | 812 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
About this model
S-120C WORKS v2 belongs to the Whyte S 120c model. Whyte released 5 bikes variations of this model so far. You can easily view all of the Whyte S 120c bikes models from 2021, here.
Model range prices
Whyte S-120C RS v3 2021 is the cheapest bike model and costs 4683$. Whyte S-120C WORKS v2 2021 is the most expensive one and costs 8211$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2021 and its price was 8211$. Doing a quick comparison, we notice that S-120C WORKS v2 price is 197.28% more expensive than the average cost of a Trail bike.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork
The fork installed on this bike is the RockShox SID model. The travel on this model is 120mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
When it comes to wheels, the S-120C WORKS v2 bike is equipped with the 29″ carbon model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
For your safety, it is important to have quality breaks on your bike. Whyte S-120C WORKS v2 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Whyte S-120C WORKS v2 includes a dropper post. Therefore, climbing or descending will be a breeze.
