Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 140mm -
Travel Rear 130mm -
Fork RockShox Pike RCT3
-
Groupset XX1, XX1 Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
RockShox Pike RCT3 27.5", DebonAir, Charger 2 with 3-position compression, Fast Black coating, 37mm offset, 15mm x 110mm, Maxle Ultimate
Rear Shock
RockShox Deluxe RT3, DebonAir, Fast Black coating, adjustable rebound, 3-position compression
Drivetrain
Rear Derailleur
SRAM XX1 Gold Eagle, 12-speed
Front Derailleur
N/A
Shift Levers
SRAM XX1 Gold Eagle, MMX, 12-speed
Cassette
SRAM XG-1299 Eagle Gold, 10-50 tooth, 12-speed
Crank
SRAM XX1 Eagle Gold Carbon, X-sync 2, DUB, 170mm
Bottom Bracket
SRAM DUB, BSA, 73mm
Chain
SRAM XX1 Gold Eagle, 12-speed
Chain Guide
None included
Pedals
None included
Wheels
Front Hub
Hope Pro 4, sealed stainless steel cartridge bearings, 15mm x 110mm Boost front, 12mm x 148mm Boost through axle rear
Rear Hub
Hope Pro 4, sealed stainless steel cartridge bearings, 15mm x 110mm Boost front, 12mm x 148mm Boost through axle rear
Rims
Whyte 30mm Carbon Hookless, 28 hole, offset, tubeless ready, 3M rim strip with valves included
Spokes
DT Swiss Competition Butted 2.0-1.8-2.0mm, black stainless, brass nipples
Tires
Front: Maxxis High Roller II TR 27.5 x 2.6" 120 tpi, EXO, 3C MaxxTerra, Rear: Maxxis Rekon TR 27.5 x 2.6" 60 tpi, EXO
Brakes
Brakes
SRAM Guide RSC, 4-piston, 180mm rotors, 160mm rear rotor (S)
Brake Levers
SRAM Guide RSC, MMX
Cockpit
Stem
Whyte Gravity, 35mm length
Handlebar
Race Face NEXT R Carbon, 35mm diameter, 800mm wide, 20mm rise
Grips
Whyte Lock-on V
Headset
FSA No. 42 Orbit ZS Plus, integrated, sealed cartridge bearings
Seat
Saddle
Whyte Custom Team, lightweight foam, chromoly rails, triple panel design
Seatpost
RockShox Reverb Stealth, X1 remote, 125mm (S), 150mm (M, L, XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.35 mm | 1.3 mm | 1.26 mm |
| Bottom Bracket Height | 330 mm | 330 mm | 330 mm | 330 mm |
| Stack | 610.4 mm | 622.4 mm | 633.4 mm | 645.4 mm |
| Reach | 438.4 mm | 462.4 mm | 486.4 mm | 510.4 mm |
| Top Tube Length | 589.4 mm | 618.4 mm | 646.4 mm | 675.4 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 406.4 mm | 431.8 mm | 457.2 mm | 482.6 mm |
| Head Tube Angle | 65.6 ° | 65.6 ° | 65.6 ° | 65.6 ° |
| Head Tube Length | 112 mm | 125 mm | 140 mm | 150 mm |
| Chainstay Length | 436 mm | 436 mm | 436 mm | 436 mm |
| Wheelbase | 1169 mm | 1199 mm | 1228 mm | 1257 mm |
| Bottom Bracket Drop | 25 mm | 25 mm | 25 mm | 25 mm |
| Standover Height | 802 mm | 808 mm | 814 mm | 821 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
T-130 C Works is part of the Whyte T 130 model. There are 12 bikes that carry this model name. Take a sneak peek at all Whyte T 130 bikes models from 2019, by clicking here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Trail bikes average price
According to our math, the average price for a trustworthy Trail bike is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Trail bikes average weight
Trail bikes have an average weight of 12.98 kg (28.62 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
T-130 C Works weighs 13 kg (28.66 lbs) and is slightly heavier than the average. In short, the average Trail bike weight is 0.15% lower than this one.
T-130 C Works components
Fork
Whyte T-130 C Works 2019 bike is equipped with the RockShox Pike RCT3 fork, and has 140mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
From the factory, it comes with the RockShox Deluxe RT3 rear shock model, which has a travel of 130mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
The T-130 C Works 2019 bike is equipped with 27.5″ carbon wheels when leaving the factory. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Whyte T-130 C Works has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
Whyte T-130 C Works bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Whyte T-130 C Works comes with a dropper post. Therefore, climbing or descending will be a breeze.
