Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 130mm -
Travel Rear 130mm -
Fork RockShox Revelation RC
-
Groupset GX Eagle, Truvativ Descendant -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RockShox Revelation RC, Fast Black coating, tapered steerer, 110x15mm Boost, Maxle Ultimate
Rear Shock
RockShox Monarch Debonair RT, Fast Black coating, adjustable rebound and compression
Drivetrain
Rear Derailleur
SRAM GX Eagle, 12-speed
Front Derailleur
N/A (1x-specific)
Shift Levers
SRAM GX Eagle, MMX Clamp, 12-speed
Cassette
SRAM PG-1275 Eagle, 10-50 tooth, 12-speed
Crank
SRAM Descendant 6K Eagle
Bottom Bracket
SRAM GXP XR, BSA 73mm
Chain
SRAM GX Eagle, 12-speed
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
Alloy, double sealed cartridge bearing, 32 hole, 110x15mm Boost front, 148x12mm Boost rear
Rear Hub
Alloy, double sealed cartridge bearing, 32 hole, 110x15mm Boost front, 148x12mm Boost rear
Rims
WTB STp i29, TCS System, 32 hole, 29mm internal width
Spokes
WTB 2.0mm, black Sandvik stainless steel, brass nipples
Tires
Front: WTB Vigilante, TCS System, Light High Grip, 60tpi, 27.5" x 2.3", Rear: WTB Trail Boss, TCS System, Light Fast Rolling, 60tpi, 27.5" x 2.4"
Brakes
Brakes
SRAM Level TL, 180mm front rotor, 160mm rear rotor (170mm rear rotor on XL)
Brake Levers
SRAM Level TL, MMX Matchmaker clamp
Cockpit
Stem
Whyte Gravity, 40mm length (XS/S/M), 50mm length (L/XL)
Handlebar
Whyte Custom alloy 6061, low rise, 760mm width (30mm rise and 780mm width on XL)
Grips
Whyte lock-on V
Headset
FSA No. 57E Orbit ZS, 1.5" cartridge sealed lower bearing, 1.125" upper bearing
Seat
Saddle
Whyte Custom dual density, triple panel design
Seatpost
RockShox Reverb Stealth, 125mm travel (XS/S), 150mm travel (M/L), 170mm travel (XL), MMX remote clamp
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.35 mm | 1.31 mm | 1.27 mm | 1.25 mm |
| Bottom Bracket Height | 331 mm | 331 mm | 331 mm | 331 mm | 331 mm |
| Stack | 578.3 mm | 584.3 mm | 591.3 mm | 596.3 mm | 605.3 mm |
| Reach | 417.3 mm | 434.3 mm | 451.3 mm | 469.3 mm | 485.3 mm |
| Top Tube Length | 574 mm | 593.7 mm | 613.4 mm | 633.3 mm | 653 mm |
| Seat Tube Angle | 74 ° | 73.7 ° | 73.5 ° | 73.3 ° | 73.2 ° |
| Seat Tube Length | 368.3 mm | 406.4 mm | 431.8 mm | 457.2 mm | 482.6 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 100 mm | 107 mm | 115 mm | 120 mm | 130 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm | 422 mm | 422 mm |
| Wheelbase | 1118 mm | 1138 mm | 1158 mm | 1178 mm | 1198 mm |
| Bottom Bracket Drop | 24 mm | 24 mm | 24 mm | 24 mm | 24 mm |
| Standover Height | 763 mm | 765 mm | 768 mm | 778 mm | 788 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
T-130 S is part of the Whyte T 130 model. Whyte released 12 bikes variations of this model so far. Take a sneak peek at all Whyte T 130 bikes models from 2018, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Trail bikes average price
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Trail bikes average weight
Trail bikes weigh an average of 12.98 kg (28.62 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
Whyte T-130 S it’s weighing 14.1 kg (31.09 lbs). At this weight, is a bit heavier than average. In other words, this model is 8.63% heavier than the average Trail bike.
T-130 S components
Fork
The RockShox Revelation RC is included from the factory. It has a travel distance of 130mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
From the factory, it comes with the RockShox Monarch Debonair RT rear shock model, which has a travel of 130mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
When it comes to wheels, the T-130 S bike is equipped with the 27.5″ aluminum model. The 27.5″ wheels are a great choice for smaller riders. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The T-130 S comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
T-130 S comes in 5 sizes, that range from 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
A dropper post is included with the T-130 S. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
