Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 140mm -
Travel Rear 130mm -
Fork RockShox Revelation Charger RC
-
Groupset GX Eagle, Truvativ Descendant -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RockShox Revelation RC 27.5", DebonAir, Charger, Fast Black coating, 37mm offset, Boost 110mm x 15mm, Maxle Lite
Rear Shock
RockShox Deluxe RT, DebonAir, Fast Black coating, rebound adjustment, 3-position compression
Drivetrain
Rear Derailleur
SRAM GX Eagle, 12-speed
Front Derailleur
N/A
Shift Levers
SRAM GX Eagle, MMX, 12-speed
Cassette
SRAM PG-1275 Eagle, 10-50 tooth, 12-speed
Crank
SRAM Descendant 6K Eagle, X-sync 2, DUB, 170mm
Bottom Bracket
SRAM DUB, BSA, 73mm
Chain
SRAM GX Eagle, 12-speed
Chain Guide
None included
Pedals
None included
Wheels
Front Hub
Alloy, double sealed cartridge bearings, 15mm x 110mm front, 12mm x 148mm rear
Rear Hub
Alloy, double sealed cartridge bearings, 15mm x 110mm front, 12mm x 148mm rear
Rims
WTB ST i29 TCS 2.0 System, pinned joint, tubeless ready, 32 hole
Spokes
DT Swiss Champion 2.0mm, black stainless, brass nipples
Tires
Front: Maxxis High Roller II TR 27.5 x 2.6" 120 tpi, EXO, 3C MaxxTerra, Rear: Maxxis Rekon TR 27.5 x 2.6" 60 tpi, EXO
Brakes
Brakes
SRAM Guide T, 4-piston, 180mm rotors, 160mm rear rotor (XS, S)
Brake Levers
SRAM Guide T, Matchmaker
Cockpit
Stem
Whyte Gravity, 35mm length
Handlebar
Whyte 6061 alloy, 31.8mm diameter, 760mm wide (XS, S), 780mm wide (M, L, XL), 15mm rise (XS, S, M) 30mm rise (L, XL)
Grips
Whyte Lock-on V
Headset
FSA No. 57E Orbit ZS, sealed cartridge bearings
Seat
Saddle
Whyte Custom, dual density, triple panel design
Seatpost
KS LEV-Integra, Southpaw alloy remote lever, 100mm (XS), 125mm (S), 150mm (M, L, XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.4 mm | 1.35 mm | 1.3 mm | 1.27 mm |
| Bottom Bracket Height | 330 mm | 330 mm | 330 mm | 330 mm | 330 mm |
| Stack | 595.3 mm | 606.3 mm | 618.3 mm | 629.3 mm | 641.3 mm |
| Reach | 410.3 mm | 434.3 mm | 458.3 mm | 482.3 mm | 506.3 mm |
| Top Tube Length | 556.3 mm | 585.3 mm | 614.3 mm | 642.3 mm | 671.3 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 368.3 mm | 406.4 mm | 431.8 mm | 457.2 mm | 482.6 mm |
| Head Tube Angle | 65.6 ° | 65.6 ° | 65.6 ° | 65.6 ° | 65.6 ° |
| Head Tube Length | 100 mm | 112 mm | 125 mm | 140 mm | 150 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1136 mm | 1165 mm | 1195 mm | 1224 mm | 1253 mm |
| Bottom Bracket Drop | 25 mm | 25 mm | 25 mm | 25 mm | 25 mm |
| Standover Height | 790 mm | 798 mm | 804 mm | 810 mm | 817 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
T-130 S belongs to the Whyte T 130 model. 12 bikes variations carry this model name so far. Take a sneak peek at all Whyte T 130 bikes models from 2019, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Trail bikes average price
Our math shows that the average cost of a dependable Trail bike is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Average weight for Trail bikes
If we make a quick analysis of the average weight of a Trail bike, we get 12.98 kg (28.62 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
T-130 S weighs 14.5 kg (31.97 lbs) and is considerably heavier than the average. In short, the average Trail bike weight is 11.71% lower than this one.
Overview of components
Fork
The RockShox Revelation Charger RC is included from the factory. It has a travel distance of 140mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
Whyte T-130 S bike has the RockShox Deluxe RT model installed, and has a travel of 130mm. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
As for the wheels, Whyte T-130 S 2019, has a 27.5″ aluminum model. The 27.5″ wheels are a great choice for smaller riders. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The T-130 S has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
Whyte T-130 S bike has 5 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Whyte T-130 S includes a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
