Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 130mm -
Travel Rear 130mm -
Fork RockShox Pike RCT3
-
Groupset XX1 Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
RockShox Pike RCT3, Fast Black coating, tapered steerer, 110x15mm Boost, Maxle Ultimate
Rear Shock
RockShox Monarch Debonair RT3, Fast Black coating, adjustable rebound and compression
Drivetrain
Rear Derailleur
SRAM XX1 Eagle Gold, 12-speed
Front Derailleur
N/A (1x-specific)
Shift Levers
SRAM XX1 Eagle Gold, MMX Clamp, 12-speed
Cassette
SRAM XG-1299 Eagle Gold, 10-50 tooth, 12-speed
Crank
SRAM XX1 Carbon Eagle Gold, Boost
Bottom Bracket
SRAM GXP Team, BSA 73mm
Chain
SRAM GX Eagle Gold, 12-speed
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
Hope Pro 4, stainless steel cartridge sealed bearing, 28 hole, 110x15mm Boost front, 148x12mm Boost rear with XD driver
Rear Hub
Hope Pro 4, stainless steel cartridge sealed bearing, 28 hole, 110x15mm Boost front, 148x12mm Boost rear with XD driver
Rims
Whyte 30mm carbon hookless, 28 hole, tubeless ready, includes 3M rim strip with tubeless valves
Spokes
DT Swiss Competition butted 2.0-1.8-2.0mm, black stainless steel, brass nipples
Tires
Front: Maxxis High Roller II TR, 60tpi, 3C (Maxx Terra), EXO sidewall protection, 27.5" x 2.3", Rear: Maxxis Crossmark II TR, EXO sidewall protection, 27.5" x 2.25"
Brakes
Brakes
SRAM Guide RSC, 4-piston, 180mm front rotor, 160mm rear rotor (170mm rear rotor on XL)
Brake Levers
SRAM Guide RSC, MMX Matchmaker clamp
Cockpit
Stem
Whyte Gravity, 35mm clamp, 40mm length (M), 50mm length (L/XL)
Handlebar
Race Face Next R carbon, 35mm clamp, 20mm rise, 780mm width
Grips
Whyte lock-on V
Headset
FSA No. 42 integrated, Orbit ZS Plus, sealed cartridge bearings
Seat
Saddle
Whyte Custom Team, lightweight foam, CrMo rails, triple panel design
Seatpost
RockShox Reverb Stealth, 150mm travel (M/L), 170mm travel (XL), MMX remote clamp with X1 lever
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.31 mm | 1.27 mm | 1.25 mm |
| Bottom Bracket Height | 331 mm | 331 mm | 331 mm |
| Stack | 586.8 mm | 591.8 mm | 600.8 mm |
| Reach | 446.8 mm | 464.8 mm | 480.8 mm |
| Top Tube Length | 608.9 mm | 628.8 mm | 648.5 mm |
| Seat Tube Angle | 73.5 ° | 73.3 ° | 73.2 ° |
| Seat Tube Length | 431.8 mm | 457.2 mm | 482.6 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 115 mm | 120 mm | 130 mm |
| Chainstay Length | 417 mm | 417 mm | 417 mm |
| Wheelbase | 1154 mm | 1174 mm | 1194 mm |
| Bottom Bracket Drop | 24 mm | 24 mm | 24 mm |
| Standover Height | 763 mm | 773 mm | 783 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
About this model
T-130C Works is a Whyte T 130c model. 5 bikes variations carry this model name so far. You can easily view all of the Whyte T 130c bikes models from 2018, here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail bikes
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Trail bikes average weight
Trail bikes weigh an average of 12.98 kg (28.62 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
Whyte T-130C Works it’s weighing 12.9 kg (28.44 lbs). At this weight, is slightly lighter than average. In short, the average Trail bike weight is 0.62% higher than this one.
Overview of components
Fork
This bike has the RockShox Pike RCT3 fork installed. The fork’s travel is 130mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
Whyte T-130C Works bike has the RockShox Monarch Debonair RT3 model installed, and has a travel of 130mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
As for the wheels, Whyte T-130C Works 2018, has a 27.5″ carbon model. These wheels will provide you with more control over the bike. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Whyte T-130C Works is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
A dropper post is included with the T-130C Works. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
