Wilier ADLAR SRAM RIVAL XPLR ETAP AXS 1×12 2024
2024 Road
Estimate price |
6,194$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Rival XPLR AXS, Rival AXS -
Suspension Rigid -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
152cm - 165cm
SM
162cm - 172cm
MD
169cm - 177cm
LG
174cm - 182cm
XL
179cm - 186cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ADLAR - CARBON MONOCOQUE NHU-MOD
Suspension Fork
ADLAR - CARBON MONOCOQUE NHU-MOD
Drivetrain
Rear Derailleur
SRAM RIVAL XPLR ETAP AXS D1 MAX 44T
Shift Levers
SRAM RIVAL ETAP AXS
Cassette
SRAM XG 1251 D1 XPLR 10-44T
Crank
SRAM RIVAL 1 D1 DUB WIDE 40T
Bottom Bracket
SRAM DUB PRESSFIT 86,5 mm ROAD
Chain
SRAM RIVAL D1 12S 114 LINK
Wheels
Rims
MICHE GRAFF XL
Tires
PIRELLI CINTURATO ADVENTURE 700X45
Brakes
Brakes
SRAM RIVAL ETAP AXS
Cockpit
Stem
WILIER STEMMA S
Handlebar
RITCHEY COMP CORRALITOS
Headset
WILIER CUSTOM BEARINGS SUPERSLIM
Seat
Saddle
WILIER SADDLE ROAD TITAN RAIL M 245-144
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.36 mm | 1.39 mm | 1.41 mm | 1.44 mm | 1.46 mm |
| Stack | 544 mm | 568 mm | 592 mm | 616 mm | 640 mm |
| Reach | 401 mm | 410 mm | 419 mm | 428 mm | 437 mm |
| Top Tube Length | 548 mm | 568 mm | 589 mm | 605 mm | 627 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 74 ° | 73.5 ° |
| Seat Tube Length | 440 mm | 470 mm | 500 mm | 530 mm | 570 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 79 mm | 104 mm | 130 mm | 155 mm | 181 mm |
| Chainstay Length | 429 mm | 429 mm | 429 mm | 429 mm | 429 mm |
| Wheelbase | 1036 mm | 1054 mm | 1071 mm | 1089 mm | 1107 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 152 cm | 162 cm | 169 cm | 174 cm | 179 cm |
| Rider Max Height | 165 cm | 172 cm | 177 cm | 182 cm | 186 cm |
About this model
ADLAR SRAM RIVAL XPLR ETAP AXS 1×12 completes the Wilier Adlar model. 3 bikes variations carry this model name so far. You can easily view all of the Wilier Adlar bikes models from 2024, here.
Model range prices
Wilier ADLAR SHIMANO GRX 1X11 2024 is the cheapest bike model and costs 3929$. Wilier ADLAR SRAM RIVAL XPLR ETAP AXS 1×12 2024 is the most expensive one and costs 5734$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Gravel bikes
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, this doesn’t mean that if you spend less money on a Gravel bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Wilier ADLAR SRAM RIVAL XPLR ETAP AXS 1×12 price was 5734$. If we compare this with the average Gravel bike cost we notice that the price is 132.9% more expensive.
Overview of components
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
When leaving the production line, the ADLAR SRAM RIVAL XPLR ETAP AXS 1×12 model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Wilier ADLAR SRAM RIVAL XPLR ETAP AXS 1×12 is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
ADLAR SRAM RIVAL XPLR ETAP AXS 1×12 comes in 5 sizes, that range from 152 cm – 186 cm (4.99 ft – 6.1 ft). In short, you can easily find one that suits you.
