Wilier FILANTE HYBRID SHIMANO ULTEGRA DI2 R8170 12S + MAHLE EBIKEMOTION 2023
2023 E-bike
Estimate price |
10,819$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra Di2 -
Suspension Rigid -
Motor MAHLE mid-drive -
Battery 250 WH, 36 V, ANT+ CONNECTIVITY -
Drivetrain Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
152cm - 165cm
SM
162cm - 172cm
MD
169cm - 177cm
LG
174cm - 182cm
XL
179cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
FILANTE HY - CARBON MONOCOQUE HUS-MOD
Suspension Fork
FILANTE HY - CARBON MONOCOQUE HUS-MOD
Drivetrain
Rear Derailleur
SHIMANO ULTEGRA RD-R8150 Di2
Front Derailleur
SHIMANO ULTEGRA FD-R8150 Di2
Shift Levers
SHIMANO ULTEGRA ST-R8170 Di2
Cassette
SHIMANO ULTEGRA CS-R8100 12S
Crank
SHIMANO ULTEGRA FC-R8100
Bottom Bracket
SHIMANO ULTEGRA PRESS FIT SM-BB72
Chain
SHIMANO ULTEGRA CN-M8100 12
Wheels
Rims
WILIER TRIESTINA HY-NDR28AC DISC
Tires
VITTORIA CORSA SPEED 700X28
Brakes
Brakes
SHIMANO ULTEGRA BR-R8170
Disk Rotors
SHIMANO ULTEGRA RT-MT800 CENTER LOCK 160 mm / 140 mm
Cockpit
Handlebar
FILANTE HY BAR INTEGRATED CARBON
Headset
FSA CUSTOM BEARINGS
Seat
Saddle
PROLOGO DIMENSION 143
Motor & Battery
Motor
MAHLE X20
Battery
250 WH, 36 V, ANT+ CONNECTIVITY
Remote
COMPUTER PULSAR ONE COMPUTER PULSAR ONE
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.45 mm | 1.49 mm | 1.52 mm | 1.55 mm | 1.58 mm |
| Stack | 532 mm | 551 mm | 571 mm | 591 mm | 609 mm | 630 mm |
| Reach | 374 mm | 379 mm | 384 mm | 389 mm | 394 mm | 400 mm |
| Top Tube Length | 522 mm | 537 mm | 552 mm | 563 mm | 579 mm | 597 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 405 mm | 435 mm | 455 mm | 475 mm | 505 mm | 535 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 117 mm | 136 mm | 157 mm | 177 mm | 196 mm | 217 mm |
| Chainstay Length | 411 mm | 411 mm | 413 mm | 413 mm | 416 mm | 416 mm |
| Wheelbase | 979 mm | 987 mm | 996 mm | 1003 mm | 1017 mm | 1029 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 152 cm | 162 cm | 169 cm | 174 cm | 179 cm | 185 cm |
| Rider Max Height | 165 cm | 172 cm | 177 cm | 182 cm | 187 cm | cm |
Model Overview
FILANTE HYBRID SHIMANO ULTEGRA DI2 R8170 12S + MAHLE EBIKEMOTION is a Wilier E Filante model. 6 e-bikes variations carry this model name so far. Take a sneak peek at all Wilier E Filante e-bikes models from 2023, by clicking here.
Model range prices
Wilier FILANTE HYBRID SHIMANO ULTEGRA DI2 R8170 12S + MAHLE EBIKEMOTION 2023 is the most economical model, with a starting price of 9875$. Wilier FILANTE HYBRID SRAM RED AXS 2X12 + MAHLE EBIKEMOTION 2023 on the other hand costs 13272$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Race e-bikes
According to our math, the average price for a trustworthy Race e-bike is 4156$. However, this doesn’t mean that if you spend less money on a Race e-bike, you couldn’t get a decent one. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
At the moment of the release date, Wilier FILANTE HYBRID SHIMANO ULTEGRA DI2 R8170 12S + MAHLE EBIKEMOTION price was 9875$. Doing a quick comparison, we notice that FILANTE HYBRID SHIMANO ULTEGRA DI2 R8170 12S + MAHLE EBIKEMOTION price is 137.61% higher than the average cost of a Race e-bike.
Overview of components
Fork material
FILANTE HYBRID SHIMANO ULTEGRA DI2 R8170 12S + MAHLE EBIKEMOTION has a carbon fork, so, it’s a great addition to the e-bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
When it comes to wheels, the FILANTE HYBRID SHIMANO ULTEGRA DI2 R8170 12S + MAHLE EBIKEMOTION e-bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Wilier FILANTE HYBRID SHIMANO ULTEGRA DI2 R8170 12S + MAHLE EBIKEMOTION is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
