Wilier Filante Hybrid SHIMANO ULTEGRA DI2 R8170 12S + MAHLE X20 2023
2023 E-bike
Estimate price |
10,667$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra Di2 -
Suspension Rigid -
Motor 50Nm mid-drive -
Battery 236 WH, 36 V, ANT+ CONNECTIVITY -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
152cm - 165cm
SM
162cm - 172cm
MD
169cm - 177cm
LG
174cm - 182cm
XL
179cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
FILANTE HY - CARBON MONOCOQUE HUS-MOD
Suspension Fork
FILANTE HY - CARBON MONOCOQUE HUS-MOD
Drivetrain
Rear Derailleur
SHIMANO ULTEGRA RD-R8150 Di2
Front Derailleur
SHIMANO ULTEGRA FD-R8150 Di2
Shift Levers
SHIMANO ULTEGRA ST-R8170 Di2
Cassette
SHIMANO ULTEGRA CS-R8100 12S
Crank
SHIMANO ULTEGRA FC-R8100
Bottom Bracket
SHIMANO ULTEGRA PRESS FIT SM-BB72
Chain
SHIMANO ULTEGRA CN-M8100 12
Wheels
Rims
WILIER HY-NDR28AC
Tires
VITTORIA CORSA SPEED 700X28
Brakes
Brakes
SHIMANO ULTEGRA BR-R8170
Cockpit
Handlebar
FILANTE HY BAR INTEGRATED CARBON
Headset
WILIER CUSTOM BEARINGS SUPERSLIM
Seat
Saddle
PROLOGO DIMENSION 143
Seatpost
FILANTE CUSTOM MADE -15 mm/0 mm
Motor & Battery
Motor
50Nm
Battery
236 WH, 36 V, ANT+ CONNECTIVITY
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.46 mm | 1.49 mm | 1.53 mm | 1.55 mm | 1.58 mm |
| Stack | 526 mm | 545 mm | 565 mm | 585 mm | 603 mm | 624 mm |
| Reach | 368 mm | 373 mm | 378 mm | 383 mm | 388 mm | 394 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 450 mm | 480 mm | 500 mm | 520 mm | 540 mm | 560 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Wheelbase | 976 mm | 984 mm | 994 mm | 1001 mm | 1012 mm | 1026 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 152 cm | 162 cm | 169 cm | 174 cm | 179 cm | 185 cm |
| Rider Max Height | 165 cm | 172 cm | 177 cm | 182 cm | 187 cm | cm |
Model Overview
Filante Hybrid SHIMANO ULTEGRA DI2 R8170 12S + MAHLE X20 belongs to the Wilier E Filante model. Wilier released 11 e-bikes variations of this model so far. You can easily view all of the Wilier E Filante e-bikes models from 2023, here.
Model range prices
Wilier Filante Hybrid SHIMANO 105 DI2 2X12 + MAHLE X20 2023 is the most economical model, with a starting price of 8365$. Wilier Filante Hybrid SRAM RED AXS 2X12 + MAHLE X20 2023 on the other hand costs 13236$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Race e-bikes
If you want an acceptable Race e-bike you should know that the average price is 4156$. However, even though the average price of a Race e-bike is lower, you might still be able to get a top-quality e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2023 for 9848$. Comparing this to the average Race e-bike price, we see that the price is 136.96% higher.
Filante Hybrid SHIMANO ULTEGRA DI2 R8170 12S + MAHLE X20 components
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
The Filante Hybrid SHIMANO ULTEGRA DI2 R8170 12S + MAHLE X20 2023 e-bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
