Wilier Jena Hybrid SHIMANO GRX 1×11 FLAT BAR 2023
2023 E-bike
Estimate price |
5,700$
Weight | 13 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset GRX 800, 105 -
Suspension Rigid -
Motor MAHLE hub-drive -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
164cm - 172cm
MD
169cm - 177cm
LG
174cm - 182cm
XL
179cm - 186cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
CARBON MONOCOQUE NH-MOD
Suspension Fork
CARBON MONOCOQUE NH-MOD
Drivetrain
Rear Derailleur
SHIMANO GRX RD-RX812
Shift Levers
SHIMANO SL-RS700 FLAT 11S
Cassette
SHIMANO CS-M7000-11 11-42T
Crank
SHIMANO GRX FC-RX600-1 40T
Bottom Bracket
SHIMANO PRESSFIT BB-RS500-PB
Chain
SHIMANO GRX CN-HG601-11
Wheels
Rims
WILIER TRIESTINA HY-NDR28AC-EU
Tires
VITTORIA TERRENO DRY RIGID 700x40
Brakes
Brakes
SHIMANO BR-RS600 DISC
Disk Rotors
SHIMANO SM-RT66 160 mm 6 BOLT
Cockpit
Stem
RITCHEY COMP
Handlebar
RITCHEY FLAT BAR MTN COMP 2X BBBLK
Headset
FSA MR137 TAPERED 1"1/8 TOP - 1"1/4 BOTTOM
Seat
Saddle
SELLE ITALIA MODEL X
Motor & Battery
Motor
MAHLE EBIKEMOTION X35
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.52 mm | 1.55 mm | 1.58 mm |
| Stack | 558 mm | 584 mm | 610 mm | 635 mm |
| Reach | 375 mm | 384 mm | 394 mm | 403 mm |
| Top Tube Length | 531 mm | 555 mm | 578 mm | 602 mm |
| Seat Tube Angle | 72.8 ° | 73.7 ° | 73.1 ° | 72.8 ° |
| Seat Tube Length | 470 mm | 500 mm | 530 mm | 570 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71.5 ° | 72 ° |
| Head Tube Length | 125 mm | 150 mm | 175 mm | 200 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 164 cm | 169 cm | 174 cm | 179 cm |
| Rider Max Height | 172 cm | 177 cm | 182 cm | 186 cm |
About this model
Jena Hybrid SHIMANO GRX 1×11 FLAT BAR is a Wilier E Jena model. Wilier released 15 e-bikes variations of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Wilier Jena Hybrid SHIMANO GRX 1×11 FLAT BAR 2023 is the most economical model, with a starting price of 5203$. Wilier Jena Hybrid SHIMANO GRX Di2 2X11 2023 on the other hand costs 8388$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Gravel e-bikes average price
If you want an acceptable Gravel e-bike you should know that the average price is 3642$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
Furthermore, this bike was made available in 2023 for 5203$. Comparing this to the average Gravel e-bike price, we see that the price is 42.86% higher.
Average weight for Gravel e-bikes
On a deeper look, we notice that the average weight of a Gravel e-bike is 13.58 kg (29.94 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
With a weight of 13 kg (28.66 lbs), Wilier e-bike is slightly lighter than average. In other words, this model is 4.46% lighter than the average Gravel e-bike.
Overview of components
Fork material
The fork on this e-bike is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
When it comes to wheels, the Jena Hybrid SHIMANO GRX 1×11 FLAT BAR e-bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Wilier Jena Hybrid SHIMANO GRX 1×11 FLAT BAR is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
Jena Hybrid SHIMANO GRX 1×11 FLAT BAR comes in 4 sizes, that range from 164 cm – 186 cm (5.38 ft – 6.1 ft). In short, you can easily find one that suits you.
