Wilier TRIESTINA HYBRID SHIMANO 105 R7020 DROP BAR 2023
2023 E-bike
Estimate price |
4,537$
Weight | 13.1 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 700c -
Groupset 105 -
Suspension Rigid -
Motor MAHLE hub-drive -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 165cm
SM
155cm - 170cm
MD
167cm - 178cm
LG
175cm - 188cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
TRIESTINA HYBRID - ALU 6061, DOUBLE BUTTED
Suspension Fork
TRIESTINA HYBRID CARBON MONOCOQUE
Drivetrain
Rear Derailleur
SHIMANO 105 RD-R7000-SS
Front Derailleur
SHIMANO 105 FD-R7000
Shift Levers
SHIMANO 105 ST-R7020
Cassette
SHIMANO 105 CS-R7000 11-30T
Crank
SHIMANO 105 FC-R7000 50-34T
Bottom Bracket
SHIMANO PRESSFIT BB-RS500-PB
Chain
SHIMANO CN-HG600-11
Wheels
Rims
WILIER TRIESTINA HY-NDR28AC
Tires
VITTORIA ZAFFIRO PRO 4 700X28
Brakes
Brakes
SHIMANO 105 BR-R7020
Disk Rotors
SHIMANO SM-RT66 6 BOLTS 160 mm / 160 mm
Cockpit
Stem
FSA OS-168 - CUSTOM WILIER
Handlebar
FSA OMEGA
Headset
RITCHEY PRD15862
Seat
Saddle
SELLE ITALIA MODEL X
Motor & Battery
Motor
MAHLE EBIKEMOTION X35+
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.46 mm | 1.49 mm | 1.53 mm | 1.55 mm |
| Stack | 526 mm | 545 mm | 565 mm | 585 mm | 603 mm |
| Reach | 368 mm | 373 mm | 378 mm | 383 mm | 388 mm |
| Top Tube Length | 514 mm | 530 mm | 546 mm | 557 mm | 573 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 450 mm | 480 mm | 500 mm | 520 mm | 540 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 117 mm | 136 mm | 157 mm | 177 mm | 196 mm |
| Chainstay Length | 405 mm | 405 mm | 407 mm | 407 mm | 410 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 155 cm | 167 cm | 175 cm | 185 cm |
| Rider Max Height | 165 cm | 170 cm | 178 cm | 188 cm | 195 cm |
About this model
TRIESTINA HYBRID SHIMANO 105 R7020 DROP BAR is part of the Wilier E Triestina model. 13 e-bikes variations carry this model name so far. You can easily view all of the Wilier E Triestina e-bikes models from 2023, here.
Model range prices
Wilier TRIESTINA HYBRID SHIMANO GRX 1X11 FLAT BAR 2023 is the cheapest e-bike model and costs 3663$. Wilier TRIESTINA HYBRID SHIMANO 105 R7020 DROP BAR 2023 is the most expensive one and costs 4141$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Hybrid e-bikes
If you want an acceptable Hybrid e-bike you should know that the average price is 2480$. However, even though the average price of a Hybrid e-bike is lower, you might still be able to get a top-quality e-bike. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2023 for 4141$. Doing a quick comparison, we notice that TRIESTINA HYBRID SHIMANO 105 R7020 DROP BAR price is 66.98% higher than the average cost of a Hybrid e-bike.
Average weight for Hybrid e-bikes
The average weight for Hybrid e-bikes is 23.79 kg (52.45 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
TRIESTINA HYBRID SHIMANO 105 R7020 DROP BAR weighs 13.1 kg (28.88 lbs) and is much lighter than the average. In conclusion, the average Hybrid e-bike weighs 81.6% more than TRIESTINA HYBRID SHIMANO 105 R7020 DROP BAR.
Overview of components
Fork material
TRIESTINA HYBRID SHIMANO 105 R7020 DROP BAR has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
The TRIESTINA HYBRID SHIMANO 105 R7020 DROP BAR 2023 e-bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The TRIESTINA HYBRID SHIMANO 105 R7020 DROP BAR comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
Wilier TRIESTINA HYBRID SHIMANO 105 R7020 DROP BAR e-bike has 5 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
