Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 50mm -
Fork Suntour M 3010
-
Groupset Tourney -
Suspension Hardtail -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Winora, Aluminium 6061, multiformed, Aluminium 6061
Suspension Fork
SR Suntour, M3010, Steel spring, 50 mm travel, Steel steerer tube 1 1/8"
Drivetrain
Rear Derailleur
Shimano, Tourney TY300
Shift Levers
Shimano, Tourney EF41, Rapidfire
Cassette
Shimano, TZ31, 14 - 34 teeth
Crank
Shimano, TY301, Aluminium, 24 - 42 - 32 teeth
Bottom Bracket
VP, BC75T, BSA
Chain
KMC, Z51
Pedals
Feimin, Plastic, FP-806B, Non Slip
Wheels
Rims
XLC, FW, Double Wall, Aluminium
Spokes
black
Tires
CST, C-1437, 53-559, 0. inch
Brakes
Brakes
Rim
Brake Levers
Shimano, EF41
Cockpit
Stem
aluminium, A-head
Handlebar
ATB handlebar
Grips
kid's grips
Headset
Feimin, A-Head 1 1/8", Ball bearing
Seat
Saddle
Winora, ATB
Seatpost
Aluminium, Patent, 27.2 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 35cm | 40cm | 45cm | 50cm |
|---|---|---|---|---|
| Stack Reach Ratio | 0.193 mm | 0.187 mm | 0.2 mm | 0.208 mm |
| Reach | 503 mm | 518 mm | 535 mm | 557 mm |
| Top Tube Length | 535 mm | 550 mm | 570 mm | 595 mm |
| Seat Tube Angle | 72 ° | 72 ° | 72 ° | 72 ° |
| Seat Tube Length | 350 mm | 400 mm | 450 mm | 500 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 120 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1022 mm | 1037 mm | 1057 mm | 1082 mm |
| Standover Height | 630 mm | 670 mm | 710 mm | 750 mm |
| Wheels | 26" | 26" | 26" | 26" |
About this model
Dash 26 is a Winora Dash model. There are 5 bikes that carry this model name. You can easily view all of the Winora Dash bikes models from 2024, here.
Model range prices
Winora Dash 26 21 speed 2024 is the most economical model, with a starting price of 560$. Winora Dash 24 21 speed TY300 2024 on the other hand costs 634$, and is the most expensive model.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Youth bikes
According to our calculations, the average cost of a Youth bike that is reliable is 278$. However, this doesn’t mean that if you spend less money on a Youth bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Winora Dash 26 price was 560$. Doing a quick comparison, we notice that Dash 26 price is 101.44% higher than the average cost of a Youth bike.
Dash 26 components
Fork
The Dash 26 comes factory-installed with the Suntour M 3010 fork. This has a travel range of 50mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Fork material
The fork on this bike is made out of steel, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the bike.
Wheels
When it comes to wheels, the Dash 26 bike is equipped with the 26″ aluminum model. These wheels give you great handling over your bike. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
Nothing is more important on a bike than its ability to brake properly. Winora Dash 26 is equipped with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they have problems in wet conditions.
