Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork Suntour NEX
-
Groupset Deore -
Suspension Hardtail -
Motor Bosch 250W 65Nm mid-drive -
Battery Bosch, PowerTube, 500 Wh -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Winora, Aluminium 6061, GCOPD, THT, Aluminium 6061
Suspension Fork
SR Suntour, NEX E25-HLO, Lockout, Steel spring, 63 mm travel, Aluminium steerer tube 1 1/8" - 1 1/2" tapered
Drivetrain
Rear Derailleur
Shimano, Deore M4120
Shift Levers
Shimano, Deore M4100, Trigger switch
Cassette
Shimano, CSM4100, 11 - 42 teeth
Crank
Samox, 38 teeth
Bottom Bracket
integrated in the motor
Chain
KMC, e10S
Chain Guide
SKS, Chainbow-E 38T
Pedals
VP, E461, Aluminium, with Reflector
Wheels
Rims
Ryde, Eco21, With Eyelets, Double Wall, Aluminium
Spokes
Stainless spokes
Tires
Schwalbe, Road Cruiser, 50-622, 28 x 2.0 inch
Brakes
Brakes
Hydraulic Disc
Brake Levers
Shimano, MT402, Aluminium
Cockpit
Stem
aluminium, angle ajustable, A-head, 31.8 mm
Handlebar
Ergobar, oversize, 640 mm
Grips
XLC, Comfort bo3
Headset
Feimin, A-Head Tapered, Aluminium, Cartridge
Seat
Saddle
Selle Royal, Wave
Seatpost
XLC, Aluminium, Patent suspension, 31.6 mm
Motor & Battery
Motor
Bosch, Performance Line, 250 W, 65 Nm, 25 km/h
Battery
Bosch, PowerTube, 500 Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 41cm | 46cm | 51cm | 56cm | 61cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.592 mm | 1.553 mm | 1.603 mm | 1.566 mm | 1.53 mm |
| Stack | 643 mm | 643 mm | 667 mm | 667 mm | 667 mm |
| Reach | 404 mm | 414 mm | 416 mm | 426 mm | 436 mm |
| Top Tube Length | 620 mm | 626 mm | 626 mm | 640 mm | 648 mm |
| Seat Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 180 mm | 180 mm | 210 mm | 210 mm | 210 mm |
| Chainstay Length | 480 mm | 480 mm | 480 mm | 480 mm | 480 mm |
| Wheelbase | 1140 mm | 1150 mm | 1160 mm | 1170 mm | 1180 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
Tria 10 completes the Winora E Tria model. Winora launched 9 e-bikes of this model so far. Take a sneak peek at all Winora E Tria e-bikes models from 2024, by clicking here.
Model range prices
Winora Tria 7 eco 2024 is the most economical model, with a starting price of 2752$. Winora Tria 10 2024 on the other hand costs 3282$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Commuter e-bikes average price
If you want an acceptable Commuter e-bike you should know that the average price is 2569$. However, even if your budget is less than the average, you might still be able to get a top-quality Commuter e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 3282$. If we compare this with the average Commuter e-bike cost we notice that the price is 27.75% more expensive.
Overview of components
Fork
This e-bike has the Suntour NEX fork installed. The fork’s travel is 63mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Fork material
When it comes to the fork, this e-bike has an aluminum one, which doesn’t add too much extra weight to the e-bike. However, it is not so stiff as steel or carbon forks are.
Wheels
As for the wheels, Winora Tria 10 2024, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Winora Tria 10 is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
