winora Yakun R5 Pro 2024
2024 E-bike
Estimate price |
5,816$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 80mm -
Fork RockShox Recon Silver RL
-
Groupset Nexus, Gates -
Suspension Hardtail -
Motor Bosch 250W 85Nm mid-drive -
Battery Bosch, PowerTube, 750 Wh -
Drivetrain Belt Drive, Internally Geared Hub -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Winora, Aluminium 6061, hydroformed, THT, GCI, Aluminium 6061
Suspension Fork
RockShox, Recon RL, Air, 80 mm travel, Aluminium steerer tube 1 1/8" - 1 1/2" tapered, 15 x 110mm thru-axle Boost
Drivetrain
Shift Levers
Shimano, Nexus, Twist shifter
Cassette
Gates, sprocket
Crank
Gates, Aluminium, 46 teeth
Bottom Bracket
integrated in the motor
Chain
Gates, CarbonDrive
Pedals
VP, 625
Wheels
Rims
Schürmann, Yak25, With Eyelets, Double Wall, Aluminium
Spokes
Sapim, Leader
Tires
Schwalbe, Al Grounder Performance, 60-584, 27.5 x 2.4 inch
Brakes
Brakes
Rim
Brake Levers
Shimano, XT T8100, Aluminium
Cockpit
Stem
aluminium, angle ajustable, A-head, 31.8 mm
Handlebar
Ergoriser, oversize, 720 mm
Grips
Herrmans, Click Ergo - lock on grips
Headset
Feimin, A-Head Tapered, Aluminium, CartridgeCane Creek, Viscoset, Aluminium
Seat
Saddle
Selle Royal, VivoErgo
Seatpost
Haibike Components, Dropper-Post Remote 34.9, Aluminium, Telescope, 34.9 mm
Motor & Battery
Motor
Bosch, Performance CX Smart System, 250 W, 85 Nm
Battery
Bosch, PowerTube, 750 Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 45cm | 50cm | 55cm | 60cm |
|---|---|---|---|---|
| Stack Reach Ratio | 1.408 mm | 1.391 mm | 1.372 mm | 1.354 mm |
| Front Center | 716 mm | 732 mm | 749 mm | 765 mm |
| Rake | 46 mm | 45 mm | 46 mm | 46 mm |
| Trail | 68 mm | 69 mm | 68 mm | 68 mm |
| Stack | 645 mm | 655 mm | 664 mm | 673 mm |
| Reach | 458 mm | 471 mm | 484 mm | 497 mm |
| Top Tube Length | 595 mm | 610 mm | 625 mm | 640 mm |
| Seat Tube Angle | 78 ° | 78 ° | 78 ° | 78 ° |
| Seat Tube Length | 450 mm | 500 mm | 550 mm | 600 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 160 mm | 170 mm | 180 mm | 190 mm |
| Chainstay Length | 472 mm | 472 mm | 472 mm | 472 mm |
| Wheelbase | 1182 mm | 1198 mm | 1215 mm | 1231 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 650 | 650 | 650 | 650 |
About this model
Yakun R5 Pro completes the Winora E Yakun model. Winora released 5 e-bikes variations of this model so far. Take a sneak peek at all Winora E Yakun e-bikes models from 2024, by clicking here.
Model range prices
Winora Yakun tour 2024 is the most economical model, with a starting price of 3811$. Winora Yakun R5 Pro 2024 on the other hand costs 5294$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Commuter e-bikes average price
If you want an acceptable Commuter e-bike you should know that the average price is 2569$. However, you could also get a good Commuter e-bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 5294$. Doing a quick comparison, we notice that Yakun R5 Pro price is 106.07% higher than the average cost of a Commuter e-bike.
Overview of components
Fork
The Yakun R5 Pro comes factory-installed with the RockShox Recon Silver RL fork. This has a travel range of 80mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Fork material
The fork is made out of aluminum, so there won’t be much extra weight added to the e-bike. However, they are not so stiff as carbon forks are.
Wheels
The Yakun R5 Pro 2024 e-bike is equipped with aluminum wheels when leaving the factory. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Yakun R5 Pro has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they are not nearly as effective as hydraulic brakes are.
Dropper post
The Winora model is also equipped with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
