Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 63mm -
Fork Suntour NEX
-
Groupset Nexus, Gates -
Suspension Hardtail -
Motor Yamaha 250W 70Nm mid-drive -
Battery InTube, 630 Wh -
Drivetrain Belt Drive, Internally Geared Hub -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Winora, Aluminium 6061, Yamaha InTube 630, HD Interface, Aluminium 6061
Suspension Fork
SR Suntour, NEX E25-HLO, Lockout, Steel spring, 63 mm travel, Aluminium steerer tube 1 1/8" - 1 1/2" tapered
Drivetrain
Shift Levers
Shimano, Nexus, Twist shifter
Cassette
Gates, sprocket, 24 - teeth
Crank
Gates, Aluminium, 50 teeth
Bottom Bracket
integrated in the motor
Chain
Gates, CarbonDrive
Pedals
VP, E461, Aluminium, with Reflector
Wheels
Rims
Schürmann, Yak25, With Eyelets, Double Wall, Aluminium
Spokes
Sapim, Leader
Tires
Continental, Contact Cruiser, 62-584, 27.5 x 2.4 inch
Brakes
Brakes
Hydraulic Disc
Brake Levers
Shimano, MT402, Aluminium
Cockpit
Stem
aluminium, angle ajustable, A-head, 31.8 mm
Handlebar
Ergoriser, oversize, 720 mm
Grips
XLC, Comfort bo3
Headset
Cane Creek, Viscoset, Aluminium
Seat
Saddle
Selle Royal, Essenza
Seatpost
XLC, Aluminium, Patent suspension, 31.6 mm
Motor & Battery
Motor
Yamaha, PW-ST System, 250 W, 70 Nm, 25 km/h
Battery
InTube, 630 Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 46cm | 50cm | 54cm |
|---|---|---|---|
| Front Center | 684 mm | 705 mm | 716 mm |
| Top Tube Length | 620 mm | 640 mm | 650 |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 460 mm | 500 mm | 540 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 155 mm | 170 mm | 190 mm |
| Chainstay Length | 475 mm | 475 mm | 475 mm |
| Wheelbase | 1153 mm | 1174 mm | 1185 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm |
| Wheels | 650 | 650 | 650 |
Model Overview
Yucatan R8f completes the Winora E Yucatan model. 6 e-bikes variations carry this model name so far. You can easily view all of the Winora E Yucatan e-bikes models from 2024, here.
Model range prices
The most economical model, the Winora Yucatan 8 2024 has a starting price of 3070$. Winora Yucatan X12 Pro 2024 on the other hand is the most expensive at 4870$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Hybrid e-bikes average price
Our math shows that the average cost of a dependable Hybrid e-bike is 2480$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Hybrid e-bike. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
At the moment of the release date, Winora Yucatan R8f price was 3917$. Comparing this to the average Hybrid e-bike price, we see that the price is 57.94% higher.
Yucatan R8f components
Fork
The fork installed on this bike is the Suntour NEX model. The travel on this model is 63mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Fork material
Yucatan R8f has an aluminum fork, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels
The wheels on Yucatan R8f are the aluminum type. The 650b wheels are very similar to 700c, with a slight difference in diameter. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Winora Yucatan R8f is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
