Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset GRX 800, GRX 600 -
Suspension Rigid -
Motor Yamaha 250W 70Nm mid-drive -
Battery Yamaha 500Wh with Charge-life indicator and Self-diagnosis display. Side-exiting dock station with anti-vibration mounting plate, Weight 6.61lb, 500Wh 36V, 4-hour charge time -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Yamaha Hydroformed Aluminum, Integrated battery, Water bottle boss, Tapered Headtube, Internal shift/brake hose routing
Suspension Fork
Fork One-Piece Aluminum, 12x100mm Thru-Axle, Fender and rack compatible, Internal brake hose routing
Drivetrain
Rear Derailleur
Shimano GRX
Shift Levers
Shimano GRX 11-speed RX600
Cassette
Shimano CS-M7000, 11-42t, 11-Speed
Crank
Shimano GRX 44t, Square taper, 165mm (S, M), 170mm (L)
Chain
KMC e11 Turbo EPT
Wheels
Front Hub
Front: 12x100mm TA, Rear: 12x142mm TA with integrated speed sensor
Rear Hub
Front: 12x100mm TA, Rear: 12x142mm TA with integrated speed sensor
Rims
32-Hole Dual Channel Welded Pin w/ Eyeleted Spoke
Spokes
Spokes SUS304
Tires
Maxxis Rambler 700 x 45c TR EXO 120tpi
Brakes
Brakes
Shimano GRX RX600-rear, RX400-front, 180mm Centerlock
Cockpit
Stem
Yamaha Alloy 4-bolt faceplate, 31.8 diameter, 80mm length (S), 90mm length (M), 100mm length (L)
Handlebar
Flare drop, 31.8mm diameter, 44cm width
Headset
Integrated bearing with 30mm of spacers
Seat
Saddle
Yamaha Off-Road Cro-Mo Rail
Seatpost
Alloy 30.9 x 340mm (S), 395mm (M), 440mm (L) with 2-bolt adjustable tilt saddle rail clamp
Motor & Battery
Motor
Yamaha PWSeries, ST 3-bolt Mount, Square Taper Spindle, Quad Sensor System with rear hub speed sensor, Weight: 7.71lb, Rated power: 250W (Nominal), 500W (Max.), Max. torque: 70Nm, Max. cadence support: xxxrpm, Max. speed support: 28mph, Support modes: AUTO, ECO+, ECO, STANDARD, HIGH
Battery
Yamaha 500Wh with Charge-life indicator and Self-diagnosis display. Side-exiting dock station with anti-vibration mounting plate, Weight 6.61lb, 500Wh 36V, 4-hour charge time
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.63 mm | 1.6 mm | 1.54 mm |
| Bottom Bracket Height | 263 mm | 263 mm | 263 mm |
| Front Center | 603 mm | 614 mm | 636 mm |
| Rake | 49 mm | 50 mm | 49 mm |
| Trail | 64 mm | 59 mm | 59 mm |
| Stack | 590 mm | 602 mm | 612 mm |
| Reach | 363 mm | 377 mm | 397 mm |
| Top Tube Length | 530 mm | 560 mm | 590 mm |
| Seat Tube Angle | 74.4 ° | 73.3 ° | 72.6 ° |
| Seat Tube Length | 429 mm | 490 mm | 551 mm |
| Head Tube Angle | 71.1 ° | 71.8 ° | 71.9 ° |
| Head Tube Length | 121 mm | 131 mm | 142 mm |
| Chainstay Length | 459 mm | 459 mm | 459 mm |
| Wheelbase | 1052 mm | 1063 mm | 1085 mm |
| Bottom Bracket Drop | 73 mm | 73 mm | 73 mm |
| Standover Height | 776 mm | 813 mm | 847 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
Wabash RT belongs to the Yamaha E Wabash model. Yamaha released 5 e-bikes variations of this model so far. Take a sneak peek at all Yamaha E Wabash e-bikes models from 2022, by clicking here.
Model range prices
The most economical model, the Yamaha Wabash 2022 has a starting price of 3499$. Yamaha Wabash RT 2022 on the other hand is the most expensive at 4199$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Endurance e-bikes
If you want an acceptable Endurance e-bike you should know that the average price is 3800$. However, this doesn’t mean that if you spend less money on an Endurance e-bike, you couldn’t get a decent one. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 4199$. Doing a quick comparison, we notice that Wabash RT price is 10.5% more expensive than the average cost of an Endurance e-bike.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork material
Wabash RT has an aluminum fork, which doesn’t add too much extra weight to the e-bike. However, it is not so stiff as steel or carbon forks are.
Wheels size
The Wabash RT 2022 e-bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Wabash RT comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
Wabash RT comes in 3 sizes, that range from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, finding one for you shouldn’t be a problem.
