Yeti SB115 T/Series Frameset 2022
2022 Mountain
Estimate price |
4,000$
Weight | 2.72 kg
Bike details
Overview
Key information split into simple groups.
Frame summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Rear 115mm -
Suspension Full
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
TURQ Series carbon fiber frame, Switch Infinity suspension technology, press-fit BB92, internally tunneled cable routing, 148mm x 12mm BOOST dropouts, sealed enduro max pivot bearings, integrated derailleur hanger, and axle.
Rear Shock
FOX FACTORY FLOAT DPS
Drivetrain
Bottom Bracket
BB86/BB92, press-fit
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.44 mm | 1.41 mm | 1.39 mm |
| Bottom Bracket Height | 341.9 mm | 341.9 mm | 341.9 mm | 341.9 mm |
| Front Center | 690.3 mm | 719.3 mm | 745.4 mm | 773.4 mm |
| Stack | 596.7 mm | 606.8 mm | 621.9 mm | 642 mm |
| Reach | 397.5 mm | 422.6 mm | 442.6 mm | 462.5 mm |
| Top Tube Length | 570.6 mm | 599.1 mm | 624.3 mm | 651.2 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 393 mm | 419 mm | 457 mm | 495 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 96.2 mm | 107 mm | 123.2 mm | 144.7 mm |
| Chainstay Length | 433 mm | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1124 mm | 1153 mm | 1179 mm | 1207 mm |
| Bottom Bracket Drop | 33 mm | 33 mm | 33 mm | 33 mm |
| Standover Height | 727 mm | 726 mm | 727 mm | 727 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
SB115 T/Series Frameset is part of the Yeti Sb115 model. 20 frames variations carry this model name so far. Take a sneak peek at all Yeti Sb115 frames models from 2022, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Crosscountry frames average price
If you want an acceptable Crosscountry frame you should know that the average price is 1689$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry frame. To make sure you don’t pay a higher amount than normal for your frame, always do some components analysis and read reviews.
When Yeti released this model in 2022, its price was 4000$. Comparing this to the average Crosscountry frame price, we see that the price is 136.83% more expensive.
Average weight for Crosscountry frames
The average weight for Crosscountry frames is 2.04 kg (4.5 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
SB115 T/Series Frameset weighs 2.72 kg (6 lbs) and is much heavier than the average. To sum up, it’s 33.33% heavier than the average weight of Crosscountry frames.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
SB115 T/Series Frameset components
Rear Shock
Yeti SB115 T/Series Frameset frame has the FOX FACTORY FLOAT DPS model installed, and has a travel of 115mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Sizes
SB115 T/Series Frameset comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
