Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 160mm -
Travel Rear 160mm -
Fork Fox Factory Float 36
-
Suspension Full -
Drivetrain Belt Drive -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
FOX FLOAT 36 Factory, Kashima coating
Rear Shock
FOX FLOAT X2 Factory, Kashima coating, 230mm x 65mm
Drivetrain
Shift Levers
Pinion rotary, 9-speed or 12-speed
Cassette
Single cog belt drive
Crank
Pinion
Bottom Bracket
Pinion C-Line gearbox
Chain
Belt
Chain Guide
Tensioner
Pedals
None
Wheels
Front Hub
Novatec, 110x15mm Boost front, 142x12mm rear with 120 points of engagement
Rear Hub
Novatec, 110x15mm Boost front, 142x12mm rear with 120 points of engagement
Rims
Zerode Carbon, 32 hole
Tires
Maxxis
Brakes
Brakes
Magura MT5, 2-piston, 6-bolt rotors (200mm front, 180mm rear)
Brake Levers
Magura MT5
Cockpit
Stem
Zerode, 45mm length
Handlebar
Zerode Z-Bar Carbon
Grips
Zerode, lock-on
Headset
Cane Creek 40, 44mm upper, 56mm lower
Seat
Saddle
Velo
Seatpost
BikeYoke Revive, 160mm or 185mm drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | LG | XL |
|---|---|---|
| Stack Reach Ratio | 1.29 mm | 1.23 mm |
| Bottom Bracket Height | 349 mm | 349 mm |
| Front Center | 802 mm | 836 mm |
| Rake | 37 mm | 37 mm |
| Trail | 141 mm | 141 mm |
| Stack | 602 mm | 610 mm |
| Reach | 467 mm | 497 mm |
| Seat Tube Angle | 75.5 ° | 75.5 ° |
| Seat Tube Length | 460 mm | 490 mm |
| Head Tube Angle | 64 ° | 64 ° |
| Head Tube Length | 110 mm | 120 mm |
| Chainstay Length | 436 mm | 436 mm |
| Wheelbase | 1237 mm | 1271 mm |
| Bottom Bracket Drop | 25 mm | 25 mm |
| Wheels | 29" | 29" |
Model Overview
Katipo Deluxe completes the Zerode Katipo model. 9 bikes variations carry this model name so far. Take a sneak peek at all Zerode Katipo bikes models from 2021, by clicking here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Enduro bikes
According to our math, the average price for a trustworthy Enduro bike is 3599$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Enduro bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Overview of components
Fork
The fork installed on this bike is the Fox Factory Float 36 model. The travel on this model is 160mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
The Katipo Deluxe has a rear shock with a travel of 160mm. The model FOX FLOAT X2 Factory is the one installed in this bike. Rear shocks improve riding comfort and give you greater control over all terrains. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
When it comes to wheels, the Katipo Deluxe bike is equipped with the 29″ carbon model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Nothing is more important on a bike than its ability to brake properly. Zerode Katipo Deluxe is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Dropper post
The Zerode model is also equipped with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
