Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 160mm -
Travel Rear 140mm -
Fork Fox Factory Float 36
-
Suspension Full -
Drivetrain Belt Drive -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
FOX FLOAT 36 Factory, Kashima coating
Rear Shock
FOX FLOAT X2 Factory, Kashima coating, 210mm x 55mm (140mm) or 216mm x 63mm (160mm)
Drivetrain
Shift Levers
Pinion rotary, 9-speed or 12-speed
Cassette
Single cog belt drive
Crank
Pinion
Bottom Bracket
Pinion C-Line gearbox
Chain
Belt
Chain Guide
Tensioner
Pedals
None
Wheels
Front Hub
Novatec, 110x15mm Boost front, 142x12mm rear with 120 points of engagement
Rear Hub
Novatec, 110x15mm Boost front, 142x12mm rear with 120 points of engagement
Rims
Stan's NoTubes Arch MK3, 32 hole
Tires
Maxxis
Brakes
Brakes
Magura MT5, 2-piston, 6-bolt rotors (200mm front, 180mm rear)
Brake Levers
Magura MT5
Cockpit
Stem
Zerode, 45mm length
Handlebar
Zerode Z-Bar Carbon
Grips
Zerode, lock-on
Headset
Cane Creek 40, 44mm upper, 56mm lower
Seat
Saddle
Velo
Seatpost
BikeYoke Revive, 125mm drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 42cm | 42cm | 140mm 5cm | 160mm 5cm | 140mm 5cm | 160mm 5cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.41 mm | 1.348 mm | 1.348 mm | 1.282 mm | 1.282 mm |
| Bottom Bracket Height | 350 mm | 350 mm | 350 mm | 350 mm | 350 mm | 350 mm |
| Front Center | 741 mm | 741 mm | 773 mm | 773 mm | 807 mm | 807 mm |
| Rake | 43 mm | 43 mm | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 118 mm | 118 mm | 115 mm | 115 mm | 115 mm | 115 mm |
| Stack | 592 mm | 592 mm | 600 mm | 600 mm | 609 mm | 609 mm |
| Reach | 420 mm | 420 mm | 445 mm | 445 mm | 475 mm | 475 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 400 mm | 400 mm | 430 mm | 430 mm | 470 mm | 470 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 110 mm | 110 mm | 120 mm | 120 mm | 130 mm | 130 mm |
| Chainstay Length | 431 mm | 431 mm | 431 mm | 431 mm | 431 mm | 431 mm |
| Wheelbase | 1172 mm | 1172 mm | 1204 mm | 1204 mm | 1238 mm | 1238 mm |
| Bottom Bracket Drop | 5 mm | 5 mm | 5 mm | 5 mm | 5 mm | 5 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" | 27" |
Model Overview
Taniwha Mulét Voyager completes the Zerode Taniwha model. There are 28 bikes that carry this model name. You can get a glimpse at all models from 2021, by clicking on this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Trail bikes average price
If you want an acceptable Trail bike you should know that the average price is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Taniwha Mulét Voyager components
Fork
The Taniwha Mulét Voyager comes factory-installed with the Fox Factory Float 36 fork. This has a travel range of 160mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
Zerode Taniwha Mulét Voyager bike has the FOX FLOAT X2 Factory model installed, and has a travel of 140mm. Rear shocks improve riding comfort and give you greater control over all terrains. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
When it comes to wheels, the Taniwha Mulét Voyager bike is equipped with the 27.5″ aluminum model. The 27.5″ wheels are a great choice for smaller riders. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Dropper post
Zerode Taniwha Mulét Voyager comes with a dropper post. Therefore, climbing or descending will be a breeze.
