Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset Ekar -
Suspension Rigid -
Drivetrain 1 × 13 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Exploro ULTRA
Suspension Fork
Fango Ultra w/ compact crown
Drivetrain
Rear Derailleur
Campagnolo EKAR 1x13
Shift Levers
Campagnolo EKAR 1x13
Cassette
Campagnolo EKAR 13-speed, 9-42T
Crank
Campagnolo EKAR carbon, 38T chainring (to match 9T smallest cog) (XXS: 165mm - 51: 170mm - 54&56: 172,5mm - 58&61: 175mm)
Wheels
Rims
Fulcrum Rapid Red 900, 650b, tubeless ready (upgrade to 3T Discus 45|40, 45|32, Plus i28 possible)
Tires
Vittoria Barzo 27,5"x2.1"
Brakes
Brakes
Campagnolo EKAR hydraulic disc w/ 160mm Campagnolo rotor
Cockpit
Stem
3T Apto Stealth
Handlebar
3T Superergo LTD carbon
Headset
Integrated headset, sealed cartridge 1-1/8"+1.5", 36°
Seat
Saddle
Selle Italia Model X Superflow
Seatpost
3T Carbon 27.2 round seatpost - Zero offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.49 mm | 1.51 mm | 1.53 mm | 1.55 mm | 1.61 mm |
| Front Center | 597 mm | 608 mm | 609 mm | 611 mm | 621 mm | 641 mm |
| Rake | 62 mm | 58 mm | 56 mm | 54 mm | 54 mm | 60 mm |
| Trail | 63 mm | 61 mm | 54 mm | 50 mm | 47 mm | 41 mm |
| Stack | 522 mm | 544 mm | 566 mm | 586 mm | 606 mm | 634 mm |
| Reach | 353 mm | 364 mm | 375 mm | 383 mm | 390 mm | 395 mm |
| Top Tube Length | 508 mm | 528 mm | 548 mm | 568 mm | 588 mm | 608 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 436 mm | 463 mm | 490 mm | 520 mm | 549 mm | 576 mm |
| Head Tube Angle | 68.5 ° | 69.5 ° | 71 ° | 72 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 125 mm | 147 mm | 161 mm | 180 mm | 201 mm | 232 mm |
| Chainstay Length | 421 mm | 421 mm | 421 mm | 421 mm | 421 mm | 421 mm |
| Wheelbase | 1005 mm | 1010 mm | 1014 mm | 1016 mm | 1026 mm | 1046 mm |
| Bottom Bracket Drop | 79 mm | 79 mm | 77 mm | 77 mm | 75 mm | 75 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 | 650 |
| Rider Min Height | 145 cm | 157 cm | 168 cm | 176 cm | 183 cm | cm |
About this model
Exploro Ultra Ekar 650b completes the 3t Exploro Ultra model. 11 bikes variations carry this model name so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
3T Exploro Ultra Rival 1X11 2023 is the most affordable bike of this model and has a price of 3699$. On the other hand, 3T EXPLORO ULTRA FORCE D2/EAGLE AXS 1X12 CRANKBROTHERS EDITION 2023, is the most expensive and costs 7300$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Gravel bikes average price
If you want an acceptable Gravel bike you should know that the average price is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When 3T released this model in 2023, its price was 5699$. Comparing the average cost of a Gravel bike to this one, you will see that Exploro Ultra Ekar 650b price is 131.48% more expensive.
Exploro Ultra Ekar 650b components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The Exploro Ultra Ekar 650b 2023 bike is equipped with aluminum wheels when leaving the factory. The 650b wheels are very similar to 700c, with a slight difference in diameter. However, if speed is what you’re after, 700c wheels are a better fit.
Brakes
Nothing is more important on a bike than its ability to brake properly. 3T Exploro Ultra Ekar 650b is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
